Air Nozzle 20E/24 E horizontal/01
Air Nozzle 15E/20E vertical/01
24
OASE Fountain Technology / Lake Management – Catalogue
Nozzles
Controllable
The compressed air driven AirNozzle is con-
trolled by DMX with the DMX-Underwater
Switch 24 V DC/DMX/02.
The use of compressed air leads to an optimized
use of energy. With the DMX-capable Underwa-
ter Switch 24 V DC / DMX/02 system costs can
be further reduced to 50 %.The different designs
provide solutions for shallow water applications.
There are four standard AirNozzles:
Air Nozzle 15 E vertical/01 (58904)
Air Nozzle 20 E vertical/01 (58904)
Air Nozzle 20 E horizontal/01 (58904)
Air Nozzle 24 E horizontal/01 (58904)
Product characteristics at a glance
•
Compact, robust stainless steel Air Nozzle
•
IP 68 in 24 voltage technology; for under-
water use
•
Pluggable, easy to install and to connect
through underwater OASE technology
•
Short refill time – up to 15 shots per minute
•
For fountain heights up to 20 m (higher foun-
tain heights on request)
•
Sea water AirNozzle on request
System integration
Generally Air Nozzles are con-
nected to a compressed air piping system where the
pipe itself acts as the air reservoir. The pipe is almost
continuously replenished by a compressor. Therefore
no additional air reservoir is required to be connected to
the Air-Nozzle. The volume of the pipe and the stand-
ard pressure should be chosen in such way that after a
shot with all nozzles the residual pressure doesn´t fall
below 90% of the default value. In more complex sup-
ply systems the target pressure can be varied in order to
achieve different jet heights.
