Spare Part Catalogue 2015 - page 47

47
FILTER- & BACHLAUFPUMPEN /
FILTER- &WATERCOURSE PUMPS
AQUAMAX
Ersatzteilkatalog 2015 / Spare part catalogue 2015
Produkt / Product
50302 AquaMax Eco CWS 4000
50303 AquaMax Eco CWS 6000
50304 AquaMax Eco CWS 8000
Pos. Produkt / Product Artikelnr. /
Item no. Ersatzteil Spare part
1 AquaMax Eco CWS 4000 – 8000 34948 Oberschale AquaMax 03 Top housing AquaMax 03
2 AquaMax Eco CWS 4000 – 8000 34945 Saugadapter AquaMax 03 Suction adapter AquaMax 03
3 AquaMax Eco CWS 4000 – 8000 34947 Regler AquaMax 03 incl. 2′ Kappe Regulator AquaMax 03 incl. 2″ cap
4 AquaMax Eco CWS 4000 – 8000 35459 Beipack Anschluss Kit AquaMax Eco 4-8000 Add. pack kit AquaMax Eco 4000 – 8000
5 AquaMax Eco CWS 4000 – 8000 34944 Unterschale AquaMax 03 Base filter housing AquaMax 03
6
AquaMax Eco CWS 4000 35460 Pumpengehäuse frosts. 2-1 D20 Pump housing anti-freeze 2-1 D20
AquaMax Eco CWS 6000 35497 Pumpengehäuse frosts. 2-1 D22 Pump housing anti-freeze 2-1 D22
AquaMax Eco CWS 8000 35785 Pumpengehäuse frosts. 2-1 D25 Pump housing anti-freeze 2-1 D25
7 AquaMax Eco CWS 4000 – 8000 3580 O-Ring NBR 80 x 3 SH75 O-Ring NBR 80 x 3 SH75
8 AquaMax Eco CWS 4000 – 8000 26002 Frostschutzschaum 2-1 Anti-freezing foam 2-1
9 AquaMax Eco CWS 4000 – 8000 34949 Frostschutzgehäuse 2-1 AquaMax 03 Anti-freeze housing 2-1 AquaMax 03
10 AquaMax Eco CWS 4000 – 8000 27949 Gummipuffer AquaMax Eco Rubber pad AquaMax Eco
11 AquaMax Eco CWS 4000 – 8000 6055 Linsenschraube V2A DIN 7985 M5 x 20 H Oval head screw V2A DIN 7985 M5 x 20 H
12 AquaMax Eco CWS 4000 – 8000 28539 O-Ring NBR 78 x 4,3 SH70 O-Ring NBR 78 x 4.3 SH70
13
AquaMax Eco CWS 4000 35513 Ersatzrotor kpl. AquaMax Eco 4000 Spare rotor cpl. AquaMax Eco 4000
AquaMax Eco CWS 6000 35514 Ersatzrotor kpl. AquaMax Eco 6000 Spare rotor cpl. AquaMax Eco 6000
AquaMax Eco CWS 8000 35515 Ersatzrotor kpl. AquaMax Eco 8000 Spare rotor cpl. AquaMax Eco 8000
14 AquaMax Eco CWS 4000 – 8000 35468 BG Zwischengehäuse EC1 vormontiert ASM inside housing EC1 pre-assembled
15 AquaMax Eco CWS 4000 – 8000 3635 O-Ring SI 76 x 4 SH50 rot/braun O-Ring SI 76 x 4 SH50 red/brown
16 AquaMax Eco CWS 4000 – 8000 25993 Schraubkappe 2′ Screw cap 2″
