H
(mWS)
Q
(l/min)
9
8
6
4
200
150
100
50
2
PondJet Eco
47
Connection possibility
for the underwater transformer of the
lighting set available as an accessory.
PondJet nozzle
with 1″ thread, cover plate and plug.
The 1″ thread allows 25 mm / 1″ foun-
tain attachments to be attached on the
multifunction nozzle of the PondJet.
Accessories: Illumination set
and fountain attachments
The optional LunAqua 10 spotlight set
wonderfully illuminates water patterns.
Additional fountain attachments are
available.
Dynamic function
The dynamic function can be activated by
a switch. Thus attractive water patterns
with different fountain heights are pro-
duced. This function enables an average
reduction in power consumption of 105W.
Top 3 product characteristics
•
Fountain pump that can be installed
quickly and easily, thanks to the fountain
aggregate with aeration effect
• New, low energy consumption motor
technology offers significant power savings
• Switchable dynamic program for impres-
sive fountains
Recommendation
Thanks to the fast and uncomplicated in-
stallation, the PondJet is perfectly suited for
short-term implementation, e.g. for events.
With the dynamic function switched on,
power consumption is up to 60% lower than
the rating of the predecessor model, thanks
to the new motor technology.
Illumination set PondJet
This set supplies an atmospheric,
illuminated fountain in the twilight
hours and consists of:
3 LunAqua 10 spotlights,
3 stainless steel holders,
1 underwater transformer
incl. special holder, 20 m cable
Item no. 57083 (page 233)
LED-floating fountain illumination
white
Item no. 42637 (page 229)
Accessories
OASE-Pump performance curves – comparison see page 286–288
*
P.293
PRODUCT DETAILS
TECHNICAL DATA
PondJet Eco
Dimensions (Ø x H)
mm
670 x 540
Rated voltage
220–240 V/50/60 Hz
Power consumption
W
190
Power cable length
m
20.00
Net weight
kg
15.20
Guarantee (+ request guarantee)*
P.293
Years
2 + 1
Max. flow rate
l/min
180
Max. flow rate
l/h
10800
Max. head height
m
8.50
Fountain height, max.
m
3.00
Connection pressure-side
mm
25
Connection pressure-side
1"
Connection suctions-side
mm
38
Connection suctions-side
1½"
Filter intake surface
cm²
420
Electronic adjustment
Yes
Number of nozzles
EA
1
Item no.
57704
Extras
FOUNTAINS & FOUNTAIN PUMPS
FLOATING FOUNTAINS
