C l u s t e r E c o 1 5 - 3 8
The Cluster Eco generates one full jet with a diam-
eter of 38 mm.
The stainless steel nozzle is designed for use in
fresh water and pool water. Since the nozzle is water
level independent and has a 3.5 mm opening, it is
suitable for installation in dry decks. (The particle
strainer diameter of the filter must be considered.)
In combination with Varionaut 270, the Cluster Eco
15-38 reaches a fountain height of approx. 6 m.
Product characteristics at a glance
•
Water saving nozzle, less water consumption
than conventional nozzles
•
21 single jets create one full jet with a jet
diameter of 38 mm of up to 10 m
•
Integrated water stabilizer with 6 deflecting
blades (OASE deflecting blade technology)
3.5
49
110
38
G1 1/2"
Cluster Eco 15-38
Dimensions
(Øx Hmm)
49 x 110
Fountain height
DWB
DDB
[l/min]
[bar]
1.00
[m]
56
0.16
2.00
[m]
79
0.28
3.00
[m]
95
0.40
4.00
[m]
111
0.55
5.00
[m]
128
0.68
6.00
[m]
140
0.81
7.00
[m]
152
0.93
8.00
[m]
164
1.05
9.00
[m]
176
1.18
10.00
[m]
187
1.32
Material
Stainless steel 1.4301 (AISI 304)
Weight
[kg]
0.6
Order no.
45480
Cluster Eco 15-38
Fresh
Water
Pool
Water
Sea
Water 220-240 V 400 V 110-120 V 50 Hz 60 Hz 12 V AC 24 V DC DMX DMX/
RDM
Plug and
Spray
Cluster Eco 15-38
*Seawater product version on request
*
•
Water level independent
•
Sea water Comet Eco Nozzle on request
Cluster Eco 15-38
