Aquarius Solar 700/1500
Q
(l/min)
10
20
30
40
50
60
H
(mWS)
2
3
1
1500
700
Extras
55
Product details
Flow regulator
Flow rate on the pump filter and fountain
height can be adjusted from the pond edge
via the regulator on the adapter.
Filter wings
Easy to remove filter wings can be fitted
on the adapters and positioned at the
edge of the pond.
Top 3 product characteristics
•
Flexible setup and operation with solar
energy only
• Perfect solution for locations without
power supply
• Removable filter wings, convenient
adjustment and cleaning from the edge
of the pond
Recommendation
The Aquarius Solar Set is part of the
OASE solar system and should ideally be
operated with the SolarModule 35 or the
SolarSafe 41.
Vulkan
Lava
Magma
Ø cm H cm Ø cm H cm
Radius/cm
H cm
40
70
25
–
50
90 Aquarius Solar 700
100 110 40
–
110 130 Aquarius Solar 1500
OASE-Pump performance curves – comparison see page 246–247
*
P.251
Accessories
SolarSafe 41
With a full rechargeable battery
the storage and control unit of
the Aquarius Solar 700/1500
enables solar operation for up
to 8 or 17 hours, even without
sunlight.
Item no. 56896
(page 213)
SolarModul 35
35W power and high
efficiency level thanks to
innovative CIS technology.
Item no. 37105
(page 213)
Hoses and accessories
Additional information on
suitable OASE hoses and
appropriate accessories
starting on page 227.
LunAqua Solar
With LEDs and a colour disc
set, ensures effective staging
above the water surface and
below the water surface.
Item no. 56894 (page 213)
Technical data
Aquarius
Solar
700
Aquarius
Solar
1500
Dimensions (L x W x H)
mm
220 x 130 x 135
Rated voltage
V
12V/DC
Power consumption
W
8
17
Power cable length
m
5.00
Net weight
kg
1.40
1.70
Guarantee (+ request guarantee)*
P.251
Years
3 + 2
Max. flow rate
l/min
12
25
Max. flow rate
l/h
700
1500
Max. head height
m
2.00
3.00
Connection pressure-side
mm
13
Connection pressure-side
½"
Connection suctions-side
mm
19/25
Connection suctions-side
¾", 1"
Connection for hoses
mm
13
Connection for hoses
½"
Filter intake surface
cm²
825
Electronic adjustment
No
Number of nozzles
EA
3
Telescopic nozzle extension
cm
16–29
Setup type
Underwater installation only
Item no.
56888
56889
Fountains & Fountain Pumps
Aquarius
