Extras
57
Connection possibility
for the underwater transformer of the
lighting set available as an accessory.
PondJet nozzle
with 1″ thread, cover plate and plug.
The 1″ thread allows 25 mm / 1″ foun-
tain attachments to be attached on the
multifunction nozzle of the PondJet Eco.
Accessories: Illumination set
and fountain attachments
The optional LunAqua 10 spotlight set
wonderfully illuminates water patterns.
Additional fountain attachments.
Top 3 product characteristics
•
Fountain pump that can be installed
quickly and easily, thanks to the fountain
aggregate with aeration effect
• New, low energy consumption motor
technology offers significant power
savings
• Switchable dynamic program for
impressive fountains
Recommendation
Thanks to the fast and uncomplicated in-
stallation, the PondJet Eco is perfectly suited
for short-term implementation, e.g. for
events. With the dynamic function switched
on, power consumption is up to 60% lower
than the rating of the predecessor model,
thanks to the new motor technology.
Illumination set PondJet
This set supplies an atmospheric,
illuminated fountain in the twilight
hours and consists of:
3 LunAqua 10 spotlights
3 stainless steel holders
1 underwater transformer
incl. special holder
20 m cable
Item no. 57083 page 203
Accessories
H
(mWS)
Q
(l/min)
9
8
6
4
200
150
100
50
2
PondJet Eco
OASE-Pump performance curves – comparison see page 246–247
*
P.251
Product details
Technical data
PondJet Eco
Dimensions (Ø x H)
mm
670 x 540
Rated voltage
220–240 V/50/60 Hz
Power consumption
W
190
Power cable length
m
20.00
Net weight
kg
15.20
Guarantee (+ request guarantee)*
P.251
Years
2 + 1
Max. flow rate
l/min
180
Max. flow rate
l/h
10800
Max. head height
m
8.50
Fountain height, max.
m
3.00
Connection pressure-side
mm
25
Connection pressure-side
1"
Connection suctions-side
mm
38
Connection suctions-side
1½"
Filter intake surface
cm²
420
Electronic adjustment
Yes
Number of nozzles
EA
1
Item no.
57704
Fountain attachments
With 1" thread for attachment on
the multifunction nozzle of the
PondJet Eco:
• Schaumsprudler 35–10 E
• Vulkan 37–2.5 K
• Vulkan 43–3 silver
Item number and product details
page 58–59
Dynamic function
The dynamic function can be activated by
a switch. Thus attractive water patterns
with different fountain heights are pro-
duced. This function enables an average
reduction in power consumption of 105 W.
Fountains & Fountain Pumps
Floating fountains
