Easy Clean technology:
Rotary switch on »Filter«
The UVC clarifier eliminates algae and
reduces pathogens. Then the »treated«
water flows through the fine mechanical
and large pored biological filter elements
of the filter unit that decompose the
pollutants and clarify the water.
Easy Clean technology:
Rotary switch on »Clean«
Turning the rotary switch activates the
cleaning function. Then move the cleaning
lever up and down to »squeeze out« the
filter elements. Simultaneously clean
water flows into the filter and forces
the polluted water out of the unit. Then
you simply return the switch to the filter
position.
Product details
Accessories
Replacement bulbs
UVC 9W
Item no. 54984 (page 232)
UVC 11W
Item no. 56112 (page 232)
UVC 18W
Item no. 56236 (page 232)
UVC 24W
Item no. 56237 (page 232)
UVC 36W
Item no. 55432 (page 232)
UVC 55W
Item no. 56636 (page 232)
Replacement foam sets
FiltoClear 3000
Item no. 56109 (page 231)
FiltoClear 6000
Item no. 56110 (page 231)
FiltoClear 12000
Item no. 51255 (page 231)
FiltoClear 16000
Item no. 51258 (page 231)
FiltoClear 20000/30000
Item no. 51290 (page 231)
FiltoCap sand
Decorative rock cover suitable
for all BioPress and FiltoClear
filters.
Item no. 50420
(page 240)
AquaActiv BioKick 200 ml
To achieve the optimal filter
effect »treatment« with
OASE BioKick filter starter is
recommended. This should be
added each time the filter is
placed in service (e.g. spring).
Item no. 50295
(page 181)
*
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
Technical data
FiltoClear
3000
FiltoClear
6000
FiltoClear
12000
FiltoClear
16000
FiltoClear
20000
FiltoClear
30000
Dimensions (Ø x H)
mm
380 x 310
380 x 430
380 x 510
380 x 630
380 x 750
Rated voltage
230 V/50 Hz
220–240 V/50/60 Hz
Power consumption
W
14
15
18
24
36
55
Power cable length
m
5.00
Net weight
kg
5.58
6.18
6.90
7.60
8.50
Guarantee (+ request guarantee)*
P.251
Years
2 + 1
UVC power
W
9
11
18
24
36
55
Number of blue filter foams
EA
2
3
4
5
Number of red filter foams
EA
1
3
2
3
4
Pollutant level indicator
Yes
Temperature display
No
Connections, inlet
mm
19/25/32/38
38/50
Connections, inlet
¾", 1", 1¼", 1½"
1½", 2"
Connections, outlet
mm
19/25/32/38
38/50
Connections, outlet
¾", 1", 1¼", 1½"
1½", 2"
Connections, sludge discharge
mm
19/25/32/38
38/50
38/50
Connections, sludge discharge
¾", 1", 1¼", 1½"
1½", 2"
1½", 2"
Max. flow rate
l/h
4000
6000
8000
10000
12000
Max. operating pressure
bar
0.20
Suitable for ponds up to max.
m³
3.0
6.0
12.0
16.0
20.0
30.0
Suitable for ponds with fish stock
m³
1.5
3.0
6.0
8.0
10.0
15.0
Suitable for ponds with koi*
1
m³
–
1.5
3.0
4.0
5.0
7.5
Item no. (GB-Version)
56051
56052
51245
51248
50580
50581
Item no.
55997
55998
51244
51247
50576
50577
Matching filters and filter systems on page 70
