Technical data
FiltoMatic
CWS
7000
FiltoMatic
CWS
14000
FiltoMatic
CWS
25000
Dimensions (L x W x H)
mm
380 x 380 x 520 380 x 380 x 720 380 x 580 x 720
Rated voltage
230 V/50 Hz
Power consumption
W
17
27
Power consumption cleaning
W
41
54
Power cable length
m
10.00
Net weight
kg
9.64
10.70
13.92
Guarantee (+ request guarantee)*
P.251
Years
2 + 1
UVC power
W
11
24
Number of filter foams, total
EA
3
6
Temperature display
Digital
UVC operating hours meter
8000 h
Connections, inlet
mm
38
Connections, inlet
1½"
Connections, outlet
DN 75
Connections, sludge discharge
DN 40
Min. flow rate
l/h
2500
3500
3500
Max. flow rate
l/h
4000
5000
6000
Suitable for ponds up to max.
m³
7.0
14.0
25.0
Suitable for ponds with fish stock
m³
3.5
7.0
12.5
Suitable for ponds with koi*
1
m³
2.0
3.5
6.5
Item no. (GB-Version)
50909
50922
50926
Item no.
50906
50910
50925
Top 3 product characteristics
•
Up to 40% power savings*
2
thanks to
UVC unit that is activated as needed
• Virtually invisible, the filter device can be
buried to 70% of the device height
• Low maintenance and user friendly
Accessories
Replacement bulb UVC
UVC 11W
Item no. 56112 (page 232)
UVC 24W
Item no. 56237 (page 232)
Filtercartridge Set
FiltoMatic CWS 7000
Item no. 50901 (page 231)
FiltoMatic CWS 14000
Item no. 50904 (page 231)
FiltoMatic CWS 25000
Item no. 50904 (page 231)
Discharge pipe
black DN 75/480 mm
Item no. 55043 (page 233)
black DN 40/480 mm
Item no. 50307
T-piece
black DN 75
Item no. 55046 (page 233)
Connection elbow
black DN 40 / 45°
Item no. 50308 (page 233)
black DN 75 / 45°
Item no. 55044 (page 233)
black DN 75 / 87°
Item no. 55045 (page 233)
Decorative rock cover
suitable for all
FiltoMatic CWS filters
FiltoMatic Cap
CWS L
Item no. 50268 (page 240)
CWS XL
Item no. 50269 (page 240)
Recommendation
Discover the other components of the
Clear Water System: The filter pump
AquaMax Eco Premium, the surface
skimmer SwimSkim 50, and the
Aerator OxyTex.
AquaActiv BioKick 200 ml
To achieve the optimal filter
effect »treatment« with OASE
BioKick filter starter is recom-
mended. This should be added
each time the filter is placed in
service (e.g. spring).
Item no. 50295 (page 181)
*
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
*
2
As compared with devices without an energy saving function in continuous operation
Product details
Matching filters and filter systems on page 70
Automatic control unit
The innovative control system ensures
energy savings through a temperature
controlled UVC unit and automatic
cleaning intervals.
Filter cover
Easy to open and close with one hand.
Unintentional opening is prevented
through integrated lock element.
Compact design
Strong filter effect in the smallest space.
With the FiltoCap the device can be
buried so that it is virtually invisible.
Cleaning
In addition to the automatic sludge dis
charge, the sponge elements are cleaned
conveniently, your hands stay clean.
