OASE | Catalogue 2015 - page 113

Extras
*
P.251
113
Brushes and mat meshwork
For separating the coarse debris.
Filter foams
For settlement of microorganisms
for decomposition of pollutants and
nutrients.
Ball valve
Clean water outlet back to the pond
lowers the water level in the filter and
enables water saving filter cleaning.
Discharge chamber
with DIN 110 connection
Product details
* 
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
Top 3 product characteristics
Large settlement surfaces for
filter bacteria
• Low maintenance multi zone filter
­system with long service life
• For large ponds up to 120 m³
Recommendation
The BioTec 30 is an important component
of the BioTec filter systems, see selection
table (page 117).
Matching filter and watercourse pumps: ­
AquaMax Eco Premium
12000 / 16000 / 20000 (page 70),
AquaMax Eco Twin 20000 / 30000 (page 76)
Matching UVC clarifiers:
Bitron C 72 W– 110W (page 140)
Bitron Eco 120 W– 220W (page 142)
AquaActiv BioKick Premium
BioKick Premium, the filter
starter for pros with more than
50 billion microorganisms /ml.
Quickly provides adequate
biology in the filter, whether
at restart or after cleaning.
Item no. 51280 (page 181)
Accessories
Replacement foam
blue BioTec 5 / 10 / 30
4x Item no. 54031 (page 231)
red BioTec 5 / 10 / 30
2x Item no. 54030 (page 231)
Discharge pipe
black DN 75/480 mm
Item no. 55043 (page 233)
black DN 110/480 mm
Item no. 50427 (page 233)
T-piece
black DN 75
Item no. 55046
(page 233)
Connection elbow
black DN 75 / 45°
Item no. 55044 (page 233)
black DN 75 / 87°
Item no. 55045 (page 233)
black DN 110 / 45°
Item no. 50430 (page 233)
Technical data
BioTec
30
Dimensions (L x W x H)
mm
1200 x 800 x 730
Net weight
kg
81.50
Guarantee*
P.251
Years
3
Number of filter brushes
EA
6
Number of filter mats
EA
5
Number of filter foams, total
EA
14
Number of blue filter foams
EA
10
Number of red filter foams
EA
4
Temperature display
No
Connections, inlet
mm
25/32/38/50
Connections, inlet
1", 1¼", 1½", 2"
Connections, outlet
DN 110
Connections, sludge discharge
DN 75
Max. flow rate
l/h
23000
Suitable for ponds up to max.
120.0
Suitable for ponds with fish stock
60.0
Suitable for ponds with koi*
1
30.0
Connection to
Bitron C 72–110 W, Bitron Eco 120–240 W
Item no.
55421
Filters & Aerators
Flow-through filters
