Extras
*
P.251
*
P.250
115
Setup possibility
Free access to the sponges through
90° setup possibility for easy and fast
maintenance.
Water distributor with flow
regulator
Adaptation of the ScreenMatic sieve to
different pump capacities for functions.
Electric motor
For electrical driving of the ScreenMatic
preliminary separator at 30 minute
intervals.
Triple separator
Frees the ScreenMatic from accumulated
debris in three stages.
Product details
Top 3 product characteristics
•
Clear and healthy pond water with
minimum maintenance requirements
• Long service life thanks to automatic
coarse debris extraction before it enters
into the filter
• Settlement surface for microorganisms
for decomposition of pollutants and
nutrients
Recommendation
The BioTec ScreenMatic flow-through filter
is an important component of the BioTec
filter systems, see selection table (page 117).
Matching Filter & watercourse pumps:
AquaMax Eco Premium 6000 / 8000 /
10000 / 12000 / 16000 / 20000 (page 70),
AquaMax Eco Twin 20000 / 30000 (page 76)
Matching UVC clarifiers:
Bitron C 36 W– 110W (page 140)
Bitron Eco 120 – 240W (page 142)
Accessories
Replacement foam
blue BioTec 12
Item no. 56738 (page 231)
red BioTec 12
Item no. 56739 (page 231)
blue BioTec 18 / 36
Item no. 56737 (page 231)
red BioTec 18 / 36
Item no. 56736 (page 231)
Discharge pipe
black DN 75/480 mm
Item no. 55043 (page 233)
black DN 110/480 mm
Item no. 50427 (page 233)
Connection elbow
black DN 75 / 45°
Item no. 55044 (page 233)
black DN 75 / 87°
Item no. 55045 (page 233)
black DN 110 / 45°
Item no. 50430 (page 233)
AquaActiv BioKick Premium
BioKick Premium, the filter
starter for pros with more than
50 billion microorganisms /ml.
Quickly provides adequate
biology in the filter, whether
at restart or after cleaning.
Item no. 51280 (page 181)
AquaActiv PhosLess
Algae protection
Binds excess phosphates, as
well as heavy metals, such as
lead and copper.
Item no. 36981
(page 183)
AquaActiv PhosLess
Refill pack
Item no. 57477 (page 183)
*
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
Technical data
BioTec
ScreenMatic
12
BioTec
ScreenMatic
18
BioTec
ScreenMatic
36
Dimensions (L x W x H)
mm
788 x 590 x 445 788 x 590 x 545 1200 x 800 x 760
Rated voltage (primary, secondary)
230 V/50 Hz, 12 V
Power consumption
W
5
Cable length 12 V device
m
2.10 (power unit) + 5.00
Net weight
kg
19.88
23.24
93.50
Guarantee*
P.251
Years
3
Number of filter foams, total
EA
16
36
Number of blue filter foams
EA
8
18
Number of red filter foams
EA
8
18
Special filter granulate
kg
3.00
6.00
18.00
Temperature display
No
Coarse debris extraction
µm
300
Connections, inlet
mm
25/32/38
25/32/38/50
Connections, inlet
1", 1¼", 1½"
1", 1¼", 1½", 2"
Connections, outlet
DN 75
DN 110
Connections, sludge discharge
DN 50
DN 75
Max. flow rate
l/h
10000
12000
23000
Suitable for ponds up to max.
m³
40.0
54.0
140.0
Suitable for ponds with fish stock
m³
20.0
27.0
70.0
Suitable for ponds with koi*
1
m³
10.0
13.5
35.0
Connection to
Bitron C 36–110W+Eco 120–240W
Item no. (GB-Version)
57213
57214
51264
Item no.
57127
57128
51259
Filters & Aerators
Flow-through filters
