125
Technical data
ProfiClear Classic
Pump chamber
ProfiClear Classic
Coarse debris extractor
ProfiClear Classic
Filter foammodule
ProfiClear Classic
Phosphate binder module
Dimensions (L x W x H)
mm
830 x 600 x 820
Net weight
kg
34.40
36.10
40.40
43.35
Guarantee (+ request guarantee)*
P.251
Years
2 + 1
Coarse debris extraction
µm
–
800
–
–
Biological filter surface
m²
–
–
90.0
148.0
Special filter granulate
kg
–
–
–
4.00
Number of blue filter foams
EA
–
–
3
–
Number of red filter foams
EA
–
–
3
–
Number of black filter foams
EA
–
–
–
6
Temperature display
No
Inlets ProfiClear Classic
2x DN 110/DN 150
1x DN 110/DN 150 + 2x DN 50
Outlets ProfiClear Classic
25–50 mm (1"–2") + 1x DN 50
1x DN 110/DN 150
Connections, sludge discharge
DN 75
Max. flow rate
l/h
25000
12500
Rec. flow rate (pumped)
l/h
–
8000
Rec. flow rate (gravitation)
l/h
–
6000
Other
Pollutant discharge incl. slide valve
Description
Whether gravity fed prin
ciple or pump fed system –
the ProfiClear Classic pump
chamber ensures optimal
pump position.
• Filters mechanically and
biologically
• Reduction of pressure
losses
• Safe and standard confor
mant set up for swim
ponds
• Easy maintenance and
winter care
• Protection against exces
sive silt
• Two inlets
1
incl. regula
tor for individual adjust
ment of the inflow
• Debris that accumulates
in the sediment tank is
flushed out via the bottom
drain
2
Enables easy mechanical
extraction of solids up to
800 µm in size.
• Incoming water is fed via
two large-surface extrac
tion sieves
1
into the next
filter chamber
• Pulling the slide valve
2
flushes out the debris via a
DN 75 discharge
• Incl. hose coupling for
fresh water rinsing
• The extraction sieves are
quickly cleaned by interior
and exterior brushes by
operating the cleaning
handle
3
• A pollutant level indicator
4
signals when mainte
nance is required
• Automatic and regular
cleaning is possible via
the ProfiClear Screendrive
(optional accessory)
Reliably removes toxins such
as ammonium/ammonia or
nitrite.
• The water to be filtered is
channelled through the
coarse and fine foams
1
that contain the vital filter
biology
• The oxygen necessary for
the nitrification processes
is supplied via connections
on the housing
• The foams are cleaned by
being compressed against
the intermediate floors via
the cleaning levers
2
• Pulling the slide valve
3
flushes the debris out via
a DN 75 discharge, which
can be supported through
rinsing via cleaning nozzles
Converts nitrate into gaseous
nitrogen (denitrification) and
eliminates phosphates.
• A majority of the water
is channelled past the
1
filter foam. This establi
shes the low oxygen mili
eu that is so important for
the denitrifying bacteria
• The lesser portion of the
flow volume is channelled
through the PhosLess
inserts
2
(4 units)
• Binders ensure quick and
safe phosphate removal
• Elimination of these
nutrients significantly
restricts string algae
growth
• Virtually maintenance free
due to bypass regulation
in the foam prevents
clogging
• A pollutant level indicator
3
signals when mainte
nance is required
• Pollutant discharge
4
incl. slide valve
Item no.
51061
51064
51065
51066
A
B
C
D
Filters & Aerators
Module filters
