Intelligence sets the pace. The intelligent
switch centre removes coarse debris to
60 µm – i.e. finer than a hair.
• Maximum partical removal to 60 µm
and flow-through rates to 25 m³/h for
pump fed. 33 m³/h for gravity for a
crystal clear view
• Automatic self-cleaning offers maximum
convenience
• Rinsing is executed with cleaned pond
water, a water connection is not required
• A watertight microcontroller system
monitors and controls the main functions,
operation is as easy as child’s play
(Plug&Play)
• Control systemwith retrospective
display of errors in running operation,
as well as adjustment possibilities for
forced cleaning, duration of cleaning
and supplemental cleaning
• Pollutant rakes on the sieves reliably remove
string algae and other larger particles from
the drum
• Pollutant trough made of ductile EPDMma
terial prevents jamming of larger particles
• VDE testing certifies reliable and safe func
tions
• Flexible implementation possibilities; can be
used in the gravity fed system, as well as in
the pump fed system
• Safety level switch in the pumped system
prevents jamming due to debris particles
• Stable housing thanks to solid stainless steel
elements and dimensionally stable Duroplast
• Individually removable sieve elements
(no tools required) and free-wheeling
functions for easy access to the drum
• Incomparably quiet through extensive
noise damping
• Powerful, high quality pressure pump is
integrated for flushing the drum
• Full flexibility for the connection with
up to 4 x DN 110 inlets (1 x optional)
• Screen elements in 150 µmmesh width
optionally available as accessories
Drum filter module
Hel-X ensures optimummedia circulation,
Original Hel-X biomedia are highly effective
at degrading pollutants in the moving bed
process.
• Extremely large, protected settlement
surface for microorganisms (704 m²/m³)
• Innovative bypass technology for optimal
movement of the Hel-X bio-elements,
even at high flow rates
• Removal of toxins, such as ammonium/
ammonia and nitrite.
• Hel-X Biomedium: 50 l decompose approx
300 g of fish food per day. Its performance
depends on temperature, feed quality and
degree of settlement of microorganisms
• Aerator bar for optimal oxygen enrich
ment and turbulence already installed
• Advantages of the moving bed process:
Permanent, optimal oxygen supply; self-
cleaning effect from dead biomass, know-
how from industrial water treatment
• Integrated bottom drain with high-quality,
finely engineered slide valve
Moving Bed Module
Integrated aerator can be connected to
AquaOxy aerator pumps.
Flexible with maximum effectiveness.
The filter system is flexibly aligned to the
individual conditions of the body of water.
• Space-saving pump and UVC chamber
for easy integration of:
AquaMax Gravity Eco filter pumps and
Bitron Gravity UVC clarifiers
• Maximum flexibility in the connection
through DN 110 and 2" ducts
• To increase the filter capacity, it is possible
to fill the individual baskets in the flow
area with additional filter medium up to
8 litres fill volume
• Integrated bottom drain with high-quality,
finely engineered slide valve
Individual module
Biological surface for settlement of the microor-
ganisms (left – biomedia that has not yet been
used, right – with settled microorganisms).
Convenient filling of the 2 individual baskets
with up to 8 litres fill volume.
Filters & Aerators
Module filters
