Extras
*
P.251
139
*
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
High quality UVC
The use of high quality UVC bulbs
guarantees a long service life, and a
constant effective irradiation capacity
Direct installation on the
BioSmart (only Vitronic 18–36W)
The Vitronic devices 18–36W can now
be directly mounted on the filter housing
of the BioSmart and BioTec models.
Visual function check
Transparent connections and a function
display on the bulb button, reliably indi-
cate the bulb function.
Closure technology
Quick release for easy bulb change and
cleaning of the quartz glass.
Top 3 product characteristics
•
Clear pond water via UVC clarification
• Highly effective against suspended algae,
bacteria and germs
• Can be combined with almost all off the
shelf filters
Accessories
Replacement bulbs UVC
UVC 11W
Item no. 56112 (page 232)
UVC 18W
Item no. 56236 (page 232)
UVC 24W
Item no. 56237 (page 232)
UVC 36W
Item no. 55432 (page 232)
UVC 55W
Item no. 56636 (page 232)
Recommendation
The UVC bulbs should be changed at
regular intervals, ideally in spring before
the season starts, to guarantee the full
strength capacity of the UVC light waves!
Product details
Technical data
Vitronic
11 W
Vitronic
18 W
Vitronic
24 W
Vitronic
36 W
Vitronic
55 W
Dimensions (L x W x H)
mm
330 x 120 x 100
529 x 186 x 130
660 x 155 x 130
Rated voltage
230 V/50 Hz
220–240 V/50/60 Hz
Power consumption
W
14
18
24
36
55
Power cable length
m
3.00
5.00
Net weight
kg
1.36
2.12
2.25
2.28
2.46
Guarantee*
P.251
Years
2
UVC power
W
11
18
24
36
55
Temperature display
No
UVC operating hours meter
No
Number of inlets
EA
1
2
Connections, inlet
mm
19/25/32/38
25/32/38
Connections, inlet
¾", 1", 1¼", 1½"
1", 1¼", 1½"
Number of outlets
EA
1
2
1
Connections, outlet
mm
19/25/32/38
25/32/38
Connections, outlet
¾", 1", 1¼", 1½"
1", 1¼", 1½"
Max. flow rate
l/h
1700
3500
4500
6000
8500
Max. operating pressure
bar
0.50
0.60
Suitable for ponds up to max.
m³
10.0
20.0
25.0
40.0
60.0
Suitable for ponds with fish stock
m³
5.0
10.0
12.5
20.0
30.0
Suitable for ponds with koi*
1
m³
2.5
5.0
6.5
10.0
15.0
Connection to
BioSmart 18000/36000, BioTec ScreenMatic 12–18
Other
Visual function check
Item no.
57370
56837
56869
56885
57373
Filters & Aerators
UVC clarifiers
