P.250
130
Technical data
ProfiClear Premium
ProfiClear Premium
Drum filter pump fed
ProfiClear Premium
Drum filter gravity fed system
Description
• Filter capacity to 60 µm and 25 m³/h for pump fed and 33 for gravity flow-through
• Automatic self cleaning
• A watertight microcontroller systemmonitors and controls the main function
• VDE testing certifies reliable and safe functions
• Gravity fed system only: Full flexibility for the connection with up to 4 x DN 110 inlets
• Safety level switch in the pumped system prevents jamming due to debris particles
• Massive stainless steel elements
• Individually removable sieve elements (no tools required) and free wheeling function
• Incomparably quiet
• High quality pressure pump is integrated for flushing the drum
• Filter capacity to 60 µm and 33 m³/h flow-through
Dimensions (L x W x H)
mm
830 x 600 x 820
Rated voltage
230 V/50 Hz
Power consumption
W
5
Power consumption cleaning
W
1050
Cable length
m
2.00 + 1.00
2.00 + 5.00
Net weight
kg
70.00
Guarantee (+request guarantee)*
P.251
Years
2 + 1
Control unit
Microcontroller
Temperature display
Digital
Coarse debris extraction
µm
60
Number of nozzles/flush quantity
4x 2.5 l/min
Flush pump
6 bar
Flush automation
Sensor, time interval, manual
Number of sieve elements
EA
8
Filter intake surface
cm²
3454
Material
GRP Duroplast/stainless steel
Number of inlets
EA
2
4
Connections, inlet
mm
50
–
Connections, inlet
2"
DN 110
Number of outlets
EA
2
Connections, outlet
DN 150
Connections, sludge discharge
DN 75, DN 110
Connection, flush trough
DN 110
Connection to
Bitron Eco, Bitron C
Bitron Gravity
Min. flow rate
l/h
10000
Max. flow rate
l/h
25000
33000
Install height above the water level
cm
40
13
Type of use
Pump fed system
Gravity fed system
Other
Pollutant discharge incl. slide valve
Item no. (GB-Version)
50774
56775
Item no.
50773
56774
1
1
Filters & Aerators
Module filters
