ProfiClear: Pump fed principle
With the pump fed principle the filter system is in­
stalled above ground, and is also above the water
level of the pond. The polluted pond water is fed
out of the pond or out of the levelled pump cham­
ber and into the filter system using a pump.
The cleaned water flows back via a freely inclined
pipeline, watercourse, or waterfall. In this process
the source of the watercourse is not higher than
the filter discharge.
System advantages at a glance:
• Can be easily retrofitted in existing ponds
• Minimum installation effort
• Easy upstream installation of UVC devices
(page 140)
• Easy to extend the system
• Optimally matched to OASE AquaMax Eco Twin /
Premium filter pumps (page 76 / 70)
The ProfiClear modular filter systems can be
­operated in two different ways depending on the
local conditions: In accordance with the gravity
fed principle or as a pump fed system.
Only Bitron C
Max. watercourse height = height of the filter discharge
Filters & Aerators
Module filters
