Extras
*
P.251
141
Technical data
Bitron C
24 W
Bitron C
36 W
Bitron C
55 W
Bitron C
72 W
Bitron C
110 W
Dimensions (L x W x H)
mm
440 x 180 x 198
600 x 180 x 198
730 x 215 x 200
Rated voltage
220–240 V/50/60 Hz
Power consumption
W
24
36
55
72
110
Power cable length
m
5.00
Net weight
kg
3.90
3.97
4.03
6.44
6.50
Guarantee*
P.251
Years
2
UVC power
W
24
36
55
72
110
Temperature display
No
Bypass control
Manually
UVC operating hours meter
No
Number of inlets
EA
1
Connections, inlet
mm
25/32/38
19/25/32/38/50
Connections, inlet
1", 1¼", 1½"
¾", 1", 1¼", 1½", 2"
Number of outlets
EA
2
Connections, outlet
mm
25/32/38
Connections, outlet
1", 1¼", 1½"
Min. flow rate
l/h
4000
8000
12000
Max. flow rate
l/h
15000
30000
40000
Max. operating pressure
bar
0.50
1.00
Suitable for ponds up to max.
25.0
40.0
60.0
75.0
110.0
Suitable for ponds with fish stock
12.5
20.0
30.0
37.5
55.0
Suitable for ponds with koi*
1
6.5
10.0
15.0
19.0
27.5
Connection to
BioSmart 18000/36000 BioSmart 18000/36000, BioTec ScreenMatic 12–18 ProfiClear, BioTec 30, ScreenMatic, Premium
Other
Visual function check
Item no.
56804
56799
56823
56901
56902
Matching filter systems on page 104, 112, 114, 124, 126
Top 3 product characteristics
Clever bypass system combines high flow
rates with duration of radiation
• Self cleaning thanks to patented
cleaning rotor
• Highly effective against suspended algae,
bacteria and germs
Automatic cleaning rotor
The automatic cleaning rotor is continuo-
usly guided around the quartz glass tube
by the water flow and prevents debris
from settling.
Closure technology
Quick release closure for easy opening of
the bulb housing. A safety switch deac-
tivates the UVC bulb automatically for
protection against eye injury.
Throttle handle
Easy adjustment of the water flow rate.
Inspection window
The function of the UVC bulb can
be checked at any time through the
inspection window.
Product details
*
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
Accessories
Replacement bulbs
UVC 24W
Item no. 56237
(page 232)
UVC 36W
Item no. 55432
(page 232)
UVC 55W
Item no. 56636
(page 232)
UVC 72W
2x Item no. 55432
(page 232)
UVC 110W
2x Item no. 56636
(page 232)
Connection elbow 2″ / 90° Bitron
for Bitron C 36W–110W and Bitron Eco
Item no. 50540 (page 233)
Recommendation
Do not forget to replace UVC bulbs regularly,
ideally in the spring!
