Extras
*
2
*
1
*
P.251
151
Top 3 product characteristics
•
Increases overall filter capacity up to 25%
• Unique combination of aeration, circula-
tion and settlement surfaces
• Harmonises with the surroundings
thanks to plant effect design
OxyTex
The OxyTex as standalone product for
previously installed aerator pumps. Incl.
adapter for 9 mm hoses.
OxyTex Set 500
The OxyTex Set 500, consisting of an
OxyTex 400 and a high performance
AquaOxy 500 pond aeration pump.
OxyTex Set 1000
The OxyTex Set 1000, consisting of an
OxyTex 1000 and a high performance
AquaOxy 1000 pond aeration pump.
OxyTex Set 2000
The OxyTex Set 2000, consisting of two
OxyTex 1000 units and a high perfor-
mance AquaOxy 2000 pond aeration
pump.
Recommendation
With an AquaOxy 4800 (page 149),
either up to four OxyTex 1000 units can
be operated at a max. depth of 1.5 m, or
a single unit can be operated at a max.
depth of 3 m. The individual OxyTex 400
and 1000 units can be operated with
a max. air displacement rate of 500 or
1000 l / h. Here as well the AquaOxy
500 – 4800 (page 149) are optimally
matched.
Product details
*
1
OxyTex 400/OxyTex Set 500
*
2
OxyTex 1000/OxyTex Set 1000–2000
Technical data
OxyTex
400
OxyTex
1000
OxyTex
Set 500
OxyTex
Set 1000
OxyTex
Set 2000
Dimensions (Ø x H)
mm
144 x 290
220 x 300
144 x 290
220 x 300
Rated voltage
–
230 V/50 Hz
–
Rated voltage (primary, secondary)
–
230 V/50 Hz , 12V/AC
Power consumption
W
–
8
15
25
Cable length 12 V device
m
–
2.00 (power unit) + 3.00
Power cable length
m
–
3.00
–
Net weight
kg
0.42
1.90
2.50
5.58
7.72
Guarantee*
P.251
Years
2
Biological filter surface
m²
1.5
3.5
1.5
3.5
7.0
Max. operating pressure
bar
0.40
Pump capacity, max.
l/h
500
1000
500
1000
2000
Hose (quantity / length / diameter)
1 Unit/5 m/4.5 mm
2 Unit/5 m/4.5 mm
Increase in filter capacity
Up to 10%
Up to 25%
Up to 10%
Up to 25%
Other
1 OxyTex, incl. 9 mm adapter
1 OxyTex
2 OxyTex
Item no. (GB-Version)
–
Not available in GB !
–
Item no.
50443
50290
57071
50249
50275
Filters & Aerators
Pond Aerators
