Extras
max.
3m
*
P.251
Technical data
AirFlo
1.5 kW/ 230 V
AirFlo
4.0 kW/ 400 V
Dimensions (Ø x H)
mm
1150 x 700
1150 x 950
Rated voltage
230 V/50 Hz
400 V/50 Hz
Power
kW
1000
4000
Rated current
A
10.20
9.60
Power cable length
m
50.00
Net weight
kg
35.50
49.50
Guarantee*
P.251
Years
2
Max. flow rate
l/h
165000
295000
Water depth, min.
m
0.90
1.15
Winterproof
No
Coarse debris displacement max.
mm
12
Item no.
50183
50185
155
Bayonet technology
for easy mounting.
Fastening material
Easy and secure anchoring of the aerator
thanks to the fastening material included
in the scope of delivery. (3 x 30 meter,
3 mm thick)
Earthing pin plug + control box
The 230V version is delivered ready to
operate with control box.
CEE connector + protection switch
The 400 version comes with a ready to
connect, 5 pole CEE connector and motor
protection switch.
Product details
Top 3 product characteristics
•
High performance aerator and decorative
floating fountain in one
• Fast and easy installation
• Variable number of lights (max. 3 x 3)
can be retrofitted
Illumination set MIDI /MAXI /AirFlo LED/ 01
This set supplies an atmospheric, illuminated fountain
in the twilight hours and consists of:
• 3 LunAqua 10 LED spotlights
• 3 stainless steel holders
• 1 underwater transformer incl. special holder
• 50 m cable
Item no. 50479 (page 203)
Accessories
Body of water size
AirFlo
1.5 kW
AirFlo
4 kW
Body of water size at least
m²
100
500
Vis. effect for bodies of water up to
m²
5000 15000
Suction depth, max.
m
4.00 5.00
Power data of the 3 »Trumpet« type
AirFlo water patterns
(Included in the scope of delivery)
AirFlo
1.5 kW
AirFlo
4 kW
Water pattern »Trumpet« M
Flow rate
l/h
165000 295000
Fountain height x width*
1
m
0.8 x 3.5 1.5 x 6
Water pattern »Trumpet« L
Flow rate
l/h
155000 265000
Fountain height x width*
1
m
1 x 5 2 x 8
Water pattern »Trumpet« XL
Flow rate
l/h
120000 225000
Fountain height x width*
1
m
2 x 6 3.0 x 10
*
1
Guide values
Filters & Aerators
Pond Aerators
