Extras
164
ProfiSkim
• Powerful suction cleaning of pond surfaces up
to 65 m² or up to 80 m²
• Ideal implementation in shallow water zones
• Can be used in gravity fed operation (DN 110)
or pump fed operation (incl. 2′ adapter)
• Water routing for effective suction capacity
• Perfect supplement for filter systems in the
gravity fed, as well as the pump fed system
The pro for the shallow water zone
• Large, easy to clean stainless steel basket with 8 mm
mesh width. On request, a debris basket with 2 mm
mesh width is available for the ProfiSkim Premium.
• ProfiSkim Premium with stable stainless steel base
for even easier installation
Top 3 product characteristics
• Powerful suction cleaning of pond
­surfaces up to 80 m²
• Can be used with large filter systems and
shallow water zones
• Perfect dimensions for large quantities of
water
Recommendation
Ensure that the skimmer is installed in a
horizontal position and confirm this with
a spirit level. Place the skimmer in such
a manner that you can execute mainte­
nance tasks, such as emptying the basket.
Schematic diagram:
ProfiSkim 100
in use
Technical data
ProfiSkim
100
ProfiSkim
Premium
Dimensions (L x W)
mm
780 x 585
500 x 340
Net weight
kg
13.06
9.10
Guarantee (+ request guarantee)*
P.251
Years
3 + 2
Height adaptation
350 mm – 550 mm
Connections, outlet
mm
50, 110
Connections, outlet
2′, DN 110
2", DN 110
Rec. flow rate (pump-fed)
l/h
10000 – 20000
6000 – 16000
Rec. flow rate (gravity-fed)
l/h
10000 – 12000
6000 – 12000
Filter volume
l
12.0
7.0
Pond surface, max.
80
65
Item no.
57134
51185
ProfiSkim
100
ProfiSkim
Premium
*
1
ProfiSkim Premium
*
2
ProfiSkim 100
*
P.251
Matching filter pumps starting on page 70
Cleaning & Care
Surface Skimmer
