Extras
162
AquaSkim
• Powerful suction cleaning of pond surfaces up to 40 m²
• The result is clearly improved water quality and viewing
depth through direct suction removal of pollutants on
the surface
• Base with large surface receptacle shell for rocks as ballast
• AquaSkim 20 – ideal for use on the AquaMax Eco Premium
4000–8000
Variable stationary and gravity fed skimmer
• AquaSkim Gravity with high quality DN 160 / 110 adapter for
easy integration in DN 110 line systems
• Easy maintenance with easily accessible coarse debris basket
• Debris basket can also be taken out from a distance via grip
hooks
• Adaptation to differences in the water level to 160 mm
• Ideal combination with AquaMax Eco Premium filter and
watercourse pumps
Top 3 product characteristics
• Powerful suction cleaning of pond
surfaces up to 40 m²
• Adaptation to changes in the water level
to 120 mm
• Supplement in the entire filter system
Recommendation
The AquaSkim is the ideal supplement for
the filter pump AquaMax Eco Premium.
Schematic diagram: AquaSkim in use with filter and watercourse pump AquaMax Eco Premium
Technical data
AquaSkim
20
AquaSkim
40
AquaSkim
Gravity
Dimensions (Ø x H)
mm
350 x 800
190 x 260
Net weight
kg
1.60
1.82
1.28
Guarantee (+ request guarantee)*
P.251
Years
3 + 2
Height adaptation
mm
370 – 850 mm 380 – 880 mm
–
Tube diameter
mm
80
110
Filter volume
l
1.2
1.4
Pos. water level difference
mm
100
120
120
Pump capacity, min.
l/h
4000
6000
Pump capacity, max.
l/h
8000
16000
Connections, outlet
mm
25 / 32 / 38
–
Connections, outlet
1", 1¼", 1½"
DN 110
Item no.
51236
56907
51237
*
1
AquaSkim 40/Gravity
*
2
AquaSkim 20
*
P.251
Cleaning & Care
Surface Skimmer
