Technical data
Bitron Gravity
55 W
Dimensions (L x W x H)
mm
700 x 260 x 160
Rated voltage
220–240 V/50/60 Hz
Power consumption
W
55
Power cable length
m
5.00
Net weight
kg
6.98
Guarantee*
P.251
Years
2
UVC power
W
55
UVC operating hours meter
No
Number of inlets
EA
1
Connections, inlet
DN 110
Number of outlets
EA
1
Connections, outlet
DN 110
Max. flow rate
l/h
30000
Max. operating pressure
bar
0.60
Rec. flow rate (gravitation)
l/h
12500
Suitable for ponds up to max.
m³
70.0
Suitable for ponds with fish stock
m³
40.0
Suitable for ponds with koi*
1
m³
25.0
Material
Plastic/stainless steel
Connection to
ProfiClear, AquaMax Gravity Eco
Type of use
Pump fed system, gravity fed system
Other
Visual function check
Item no.
50946
Extras
*
P.251
145
Product details
High quality V4A stainless
steel housing
provides stability and good reflection
rates. Can be used even with increased
salt content (dry setup).
Easy installation with
stainless steel connection elements.
Flexible installation
possible before or after the filter system.
Also ideal for other gravity fed applica-
tions.
Top 3 product characteristics
•
Powerful, efficient UVC clarifier
• Extremely effective sterilisation thanks to
well thought-out flow optimisation
• Extremely easy and flexible installation
before or after the filter system
Recommendation
Do not forget to replace UVC bulbs regularly,
ideally in the spring!
Matching filter systems on page 124 and 126
Perfect for gravity fed filter systems on koi ponds.
Can be optimally integrated in the ProfiClear Premium system.
*
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
Accessories
Replacement bulb UVC 55W
Item no. 56636 (page 232)
Discharge pipe black 110 / 480 mm
Item no. 50427 (page 233)
Adapter kit hose Bitron Gravity
Item no. 18127
Connection elbow black 110 / 45°
Item no. 50430 (page 233)
Filters & Aerators
UVC clarifiers
