113
Brushes and mat meshwork
For separating the coarse debris.
Filter foams
For settlement of microorganisms for
decomposition of pollutants and nutri-
ents.
Ball valve
Clean water outlet back to the pond
lowers the water level in the filter and
enables water saving filter cleaning.
Discharge chamber
with DIN 110 connection
PRODUCT DETAILS
*
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
Top 3 product characteristics
•
Large settlement surfaces for filter
bacteria
• Low maintenance multi zone filter
system with long service life
• For large ponds up to 120 m³
Recommendation
The BioTec 30 is an important component
of the BioTec filter systems, see selection
table (page 117).
Matching filter and watercourse pumps:
AquaMax Eco Premium 12000 /
16000 / 20000 (page 66),
AquaMax Eco Twin 20000 / 30000 (page 70)
Matching UVC clarifiers:
Bitron C72W– 110W (page 141)
Bitron Eco 120W– 220W (page 141)
AquaActiv BioKick Premium
BioKick Premium, the filter
starter for pros with more than
50 billion microorganisms/
ml. Quickly provides adequate
biology in the filter, whether at
restart or after cleaning.
Item no. 51280
(page 191)
TECHNICAL DATA
BioTec
30
Dimensions (L x W x H)
mm
1200 x 800 x 730
Net weight
kg
81.50
Guarantee*
P.293
Years
3
Number of filter brushes
EA
6
Number of filter mats
EA
5
Number of filter foams, total
EA
14
Number of blue filter foams
EA
10
Number of red filter foams
EA
4
Temperature display
No
Connections, inlet
mm
25/32/38/50
Connections, inlet
1", 1¼", 1½", 2"
Connections, outlet
DN 110
Connections, sludge discharge
DN 75
Max. flow rate
l/h
23000
Suitable for ponds up to max.
m³
120.0
Suitable for ponds with fish stock
m³
60.0
Suitable for ponds with koi*
1
m³
30.0
Connection to
Bitron C 72–110 W, Bitron Eco 120–240 W
Item no. (GB-Version)
–
Item no.
55421
Accessories
Replacement foam
blue BioTec 5 / 10 / 30
10x Item no. 54031 (page 138)
red BioTec 5/10/30
4x Item no. 54030 (page 138)
Discharge pipe
black DN 75 / 480 mm
Item no. 55043
(page 263)
black DN 110 / 480 mm
Item no. 50427
(page 263)
T-piece
black DN 75
Item no. 55046
(page 263)
Connection elbow
black DN 75 / 45°
Item no. 55044
(page 263)
black DN 75 / 87°
Item no. 55045
(page 263)
black DN 110 / 45°
Item no. 50430
(page 263)
