Intelligent function checks
Sensors detect the pollutant level and ac-
tivate the belt run automatically. An LED
display shows required cleaning measures.
Optimised water distributors
Ensures an ideal water check over a
broad pump spectrum, entirely without
narrow points susceptible to clogging.
Sludge basket
Significantly greater convenience in
handling the basket. Innovative conta-
mination barriers prevent leaking out
into the filter chamber.
Rubberised separator lip
For an even better separation result
in the case of non-uniform pollution
burden.
PRODUCT DETAILS
Top 3 product characteristics
•
Significant improvements relative to
the predecessor model
• Long service life thanks to automatic
coarse debris extraction before it enters
into the filter
• Continuous belt filter at an affordable
price
Recommendation
Please note the new allocation for the
replacement filter foams. These are now
also applicable to previous models.
*
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
TECHNICAL DATA
BioTec
ScreenMatic
2
40000
BioTec
ScreenMatic
2
60000
BioTec
ScreenMatic
2
140000
Dimensions (L x W x H)
mm
788 x 590 x 445 788 x 590 x 545 1200 x 800 x 760
Rated voltage (primary, secondary)
230 V/50 Hz, 12 V
Power consumption
W
5
Cable length 12 V device
m
2.10 (power unit) + 5.00
Net weight
kg
20.00
25.00
95.00
Guarantee (+ request guarantee)*
P.293
Years
2 + 1
Number of filter foams, total
EA
8
18
Number of blue filter foams
EA
2
4
Number of red filter foams
EA
3
7
Number of violet filter foams
EA
3
7
Special filter granulate
kg
2.50
3.50
14.50
Temperature display
No
Coarse debris extraction
µm
300
Connections, inlet
mm
25/32/38
25/32/38/50
Connections, inlet
1", 1¼", 1½"
1", 1¼", 1½", 2"
Connections, outlet
DN 75
DN 110
Connections, sludge discharge
DN 50
DN 75
Min. flow rate
l/h
4000
6000
8000
Max. flow rate
l/h
9000
11000
17500
Suitable for ponds up to max.
m³
40.0
60.0
140.0
Suitable for ponds with fish stock
m³
20.0
30.0
70.0
Suitable for ponds with koi*
1
m³
10.0
15.0
35.0
Connection to
Bitron C 36–110W+Eco 120–240W
Item no.
57694
57695
57696
Accessories
Replacement foam set BioTec 40000
red/purple
Item no. 42893
(page 138)
Replacement foam set
BioTec 60000 / 140000
red/purple
Item no. 42894
(page 138)
Replacement foam set BioTec 40000
blue
Item no. 42895
(page 138)
Replacement foam
Set BioTec 60000 / 140000
blue
Item no. 42896
(page 138)
Discharge pipe
black DN 75 / 480 mm
Item no. 55043
(page 263)
black DN 110 / 480 mm
Item no. 50427
(page 263)
Connection elbow
black DN 75 / 45°
Item no. 55044
(page 263)
black DN 110 / 45°
Item no. 50430
(page 263)
AquaActiv BioKick Premium
BioKick Premium, the filter starter
for pros with more than 50 billion
microorganisms/ml. Quickly provi-
des adequate biology in the filter,
whether at restart or after cleaning.
Item no. 51280
(page 193)
AquaActiv PumpClean 500 ml
Effective cleaner for pond
equipment, such as pumps, sieves,
quartz glass elements, etc.
Item no. 43146
(page 207)
Extras
*
P.293
*
P.292
NEW NEW
B
NEW
NEW
NEW
NEW
NEW
