125
TECHNICAL DATA
ProfiClear Classic
A
ProfiClear Classic
Pump chamber
A
ProfiClear Classic /
Compact
Pump chamber
B
ProfiClear Classic
coarse debris
extraction
C
ProfiClear Classic
filter foam
module
D
ProfiClear Classic
coarse debris
extraction
Dimensions (L x W x H)
mm
830 x 600 x 820
830 x 665 x 820
830 x 600 x 820
Net weight
kg
34.40
36.50
36.10
40.40
43.35
Guarantee (+ request guarantee)*
P.293
Years
2 + 1
Coarse debris extraction
µm
–
–
800
–
–
Biological filter surface
m²
–
–
–
90.0
148.0
Special filter granulate
kg
–
–
–
–
4.00
Number of blue filter foams
EA
–
–
–
3
–
Number of red filter foams
EA
–
–
–
3
–
Number of black filter foams
EA
–
–
–
–
6
Temperature display
No
Inlets ProfiClear Classic
2x DN 110/1xDN 150
1x DN 110/DN 150 + 2x DN 50
Outlets ProfiClear Classic
25–50 mm (1"–2") + 1x DN 50
1x 2′/2x DN 110
1x DN 110/DN 150
Connections, sludge discharge
DN 75
Max. flow rate
l/h
25000
12500
Rec. flow rate (pumped)
l/h
–
8000
Rec. flow rate (gravitation)
l/h
–
6000
Other
Pollutant discharge incl. slide valve
Product characteristics
Whether the OASE
modular filtration
system is operated
as a gravity-fed filter
in the ground or as
a pump-fed version.
The ProfiClear Clas-
sic pump chamber
ensures the correct
positioning of the
filtration pump.
• Safe and standard-
conformant setup
for swim ponds
• Easy maintenance
and winter care
• Protection against
excessive silt
• Debris that ac-
cumulates in the
sediment tank is
flushed out via the
bottom drain
1
Note:
Starting in 2016 a
DN 110 slide valve will
no longer be included
in the scope of delivery.
This can be ordered
separately as an acces-
sory item: 27171 (see
ProfiClear accessories).
Enables space-saving
and energy-efficient
integration of up to two
Aqua-Max Eco Gravity
and Bitron Gravity units.
• Maximum flexibility
in the connection
through DN 110 and
2′ ducts
• Reduction of pressure
losses
• Safe and standard-
conformant setup for
swim ponds
• Easy maintenance
and winter care
• Protection against
excessive silt
• Debris that accumu-
lates in the sediment
tank is flushed out
via the bottom
drain
1
Enables easy mechani-
cal extraction of solids
up to 800 µm in size.
• Incoming water is
fed via two large-
surface extraction
sieves
1
into the
next filter chamber
• Pulling the slide
valve
2
flushes out
the debris via a DN
75 discharge
• Incl. hose coupling
for fresh water
rinsing
• The extraction
sieves are quickly
cleaned by interior
and exterior brushes
by operating the
cleaning handle
3
• A pollutant level
indicator
4
signals
when maintenance
is required
• Automatic and regu-
lar cleaning is possi-
ble via the ProfiClear
Screendrive (optional
accessory)
The ProfiClear Classic
filter foammodule
ensures safe removal
of toxic substances like
ammonium/ammonia
or nitrite.
• The water to be fil-
tered is channelled
through the coarse
and fine foams
1
that contain the
vital filter biology
• The oxygen
necessary for the
nitrification pro-
cesses is supplied via
connections on the
housing
• The foams are
cleaned by being
compressed against
the intermediate
floors via the clean-
ing levers
2
• Pulling the slide
valve
3
flushes the
debris out via a DN
75 discharge, which
can be supported
through rinsing via
cleaning nozzles
• Incl. hose coupling
for fresh water
rinsing
The ProfiClear Classic
phosphate binder mod-
ule converts nitrate
into gaseous nitrogen
(denitrification) and
eliminates phosphates.
• A majority of the
water is chan-
nelled past the
1
filter foam. This
establishes the low
oxygen milieu that is
so important for the
denitrifying bacteria
• The lesser portion of
the flow volume is
channelled through
the PhosLess inserts
2
(4 units)
• Binders ensure quick
and safe phosphate
removal
• Elimination of
these nutrients
significantly restricts
string algae growth
• Virtually mainte-
nance-free because
bypass regulation in
the foam prevents
clogging
• A pollutant level
indicator
3
signals
when maintenance
is required
• Pollutant discharge
4
incl. slide valve
• Incl. hose coupling for
fresh water rinsing
Item no.
51061
42913
51064
51065
51066
*
P.293
*
P.292
NEW
FILTERS, UVC & AERATION
MODULAR FLOW-THROUGH FILTERS
