Flexible with maximum effectiveness.
The filter system is flexibly aligned to the
individual conditions of the body of water.
• Space-saving pump and UVC chamber
for easy integration of:
AquaMax Eco gravity filter pumps and
Bitron Gravity UVC clarifiers
• Maximum flexibility in the connection
through DN 110 and 2
"
ducts
• To increase the filter capacity, it’s possible
to fill the 2 individual baskets in the flow
area with additional filter medium up to
8 litres fill volume
• Integrated bottom drain with high quality,
finely engineered slide valve
Intelligence sets the pace. The intelligent
switch centre removes coarse debris to
60 µm – i.e. finer than a strand of hair.
• Maximum particle removal to 60 µm and
flow-through rates to 33 m³/h for a crystal
clear view
• Flexible implementation possibilities;
can be used in the gravity-fed system,
as well as in the pump-fed system
• Automatic self-cleaning offers maximum
convenience
• Rinsing is executed with cleaned pond
water, a water connection is not required
• A watertight microcontroller system
monitors and controls the main functions,
operation is as easy as child’s play
(plug & play)
• Control system with retrospective display
of errors in running operation as well as
adjustment possibilities for forced cleaning,
duration of cleaning and supplemental
cleaning
• Pollutant rakes on the sieves reliably re-
move string algae and other larger particles
from the drum
• Pollutant trough made of ductile EPDMma-
terial prevents jamming of larger particles
• VDE testing certifies reliable and safe
functions
• Safety level switch in the pump-fed system
prevents jamming due to debris particles
• Stable housing thanks to solid stainless
steel elements and dimensionally stable
Duroplast
• Individually removable sieve elements
(no tools required) and free-wheeling func-
tions for easy access to the drum interior
• Incomparably quiet through extensive
noise damping
• Powerful, high-quality pressure pump is
integrated for flushing the drum
• Full flexibility for the connection with
up to 4x DN 110 inlets
• Screen elements in 150 µmmesh width
optionally available as accessories
Hel-X ensures optimummedia circulation
Original Hel-X biomedia are highly effective
at degrading pollutants in the moving
bed process.
• Extremely large, protected settlement
surface for microorganisms (806 m²/m³)
• Innovative bypass technology for optimal
movement of the Hel-X bio-elements even
with high flow rates
• Removal of toxins, such as ammonium/
ammonia, nitrite and nitrate
• Hel-X Biomedium 50 l decompose
approx 340 g of fish food per day. Its per-
formance depends on temperature, feed
quality and the degree of settlement
of microorganisms
• Aerator bar for oxygen enrichment and
turbulence already installed
• Advantages of the moving bed process:
Permanent, optimal oxygen supply; self-
cleaning effect from dead biomass, know-
how from industrial water treatment
• Integrated bottom drain with high quality,
finely engineered slide valve
DRUM FILTER MODULE
MOVING BED MODULE
INDIVIDUAL MODULE
Integrated aerator can be connected to
AquaOxy aerator pumps.
It was possible to significantly extend the
surface that can be settled (surface protected:
+ 14.5% relative to the predecessor product).
Convenient filling of the 2 individual baskets
with up to 8 litres fill volume.
NEW
Now with
FILTERS, UVC & AERATION
MODULAR FLOW-THROUGH FILTERS
