134
Natural ponds &
swim ponds
(without fish stock)
40 m³
60 m³
80 m³
100 m³ 120 m³ 160 m³ 200 m³
Coarse debris extractor
EA
1
1
1
1
2*
2*
2*
Filter foammodule
EA
1
1
2
3
3
4
6
Phosphate binder module
EA
–
1
1
1
1
2
2
Pump chamber
EA
1
1
1
1
1
1
1
Bitron 72 W
EA
1
1
–
–
2
–
–
Bitron 110 W
EA
–
–
1
–
–
2
–
Bitron Eco 120 W
EA
–
–
–
1
–
–
2
Optional: Bitron Gravity
EA
1
1
2
2
2
2
2
Pump capacity /h = pond size / 8
* Double-row configuration (the filter systemmust be operated in two filter rows that are separate from each other) see illustration below.
This table considers the usual flow losses within the filter system.
All references regarding our Filter/UVC combinations for special pond sizes are based on Mid-European climatic conditions.
For other regions they could differ due to the water temperature and sun intensity.
How to calculate the right UVC power for your pond
Ponds
without fish stock:
1 W
UVC power per m
3
pond volume
Ponds
with fish stock:
2 W
UVC power per m
3
pond volume
Ponds
with koi stock:
4 W
UVC power per m
3
pond volume
Note: To keep the bacterial load low in the koi pond, the Bitron Gravity should be operated with a max.
flow rate of 12.5 m³/h. In this regard recirculation of 55 % of the pond volume/h should be the objective.
These recommendations are already considered in the table above.
BIOLOGICAL PERFORMANCE OF THE HEL-X
BIO MEDIUM IN THE MOVING BED MODULE:
50 l of Hel-X decomposes approx 340 g of fish food per day. If neces-
sary, the fill level already contained can be extended from 50 l to 100 l
(600 g fish food) per Moving Bed Module.
Up to 3 Moving Bed Modules
per row can be inserted in succession.
Among other factors, biological
performance depends on temperature, food quality and the degree
to which the Hel-X is settled with microorganisms.
Double-row configuration with ProfiClear Classic as the example
The filter system must be operated in two filter rows that are
separate from each other.
High
water level
Setup – pump fed system
Setup – gravity fed system
High
water level
SELECTION TABLE – PROFICLEAR CLASSIC
With fish stock
(up to 1 kg/1000 l)
20 m³
30 m³
40 m³
50 m³
60 m³
80 m³
100 m³
Coarse debris extractor
EA
1
1
1
1
2*
2*
2*
Filter foammodule
EA
1
1
2
3
3
4
6
Phosphate binder module
EA
–
1
1
1
1
2
2
Pump chamber
EA
1
1
1
1
1
1
1
Bitron 72 W
EA
1
1
–
–
2
–
–
Bitron 110 W
EA
–
–
1
–
–
2
–
Bitron Eco 120 W
EA
–
–
–
1
–
–
2
Optional: Bitron Gravity
EA
1
1
2
2
2
3
4
Pump capacity /h = pond size / 4
* Double-row configuration (the filter systemmust be operated in two filter rows that are separate from each other) see illustration below.
This table considers the usual flow losses within the filter system.
All references regarding our Filter/UVC combinations for special pond sizes are based on Mid-European climatic conditions.
For other regions they could differ due to the water temperature and sun intensity.
RULES OF THUMB
FILTERS, UVC & AERATION
MODULAR FLOW-THROUGH FILTERS
