143
*
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
High quality UVC
The use of high quality UVC bulbs gua-
rantees a long service life, and a constant
effective irradiation capacity.
Direct installation on the
BioSmart (only Vitronic 18–36W)
The Vitronic devices 18–36W can now
be directly mounted on the filter housing
of the BioSmart and BioTec models.
Inspection window
For checking the bulb function (not for
Vitronic 11W).
Closure technology
Quick release for easy bulb change and
cleaning of the quartz glass.
Accessories
Replacement bulb UVC 11W
for BioSmart UVC 16000
for BioPress Set 10000
Spare bulb for the integrated
UVC unit in the Filtral UVC 5000.
Item no. 56112 (page 150)
Replacement bulb UVC 18W Item no. 56236 (p. 150)
Replacement bulb UVC 24W Item no. 56237 (p. 150)
Replacement bulb UVC 36W Item no. 55432 (p. 150)
Replacement bulb UVC 55W Item no. 56636 (p. 150)
PRODUCT DETAILS
TECHNICAL DATA
Vitronic
11 W
Vitronic
18 W
Vitronic
24 W
Vitronic
36 W
Vitronic
55 W
Dimensions (L x W x H)
mm
330 x 120 x 100
529 x 186 x 130
660 x 155 x 130
Rated voltage
230 V/50 Hz
220–240 V/50/60 Hz
Power consumption
W
14
18
24
36
55
Power cable length
m
3.00
5.00
Net weight
kg
1.36
2.12
2.25
2.28
2.30
Guarantee*
P.293
Years
2
UVC power
W
11
18
24
36
55
Temperature display
No
UVC operating hours meter
No
Number of inlets
EA
1
2
Connections, inlet
mm
19/25/32/38
25/32/38
Connections, inlet
¾", 1", 1¼", 1½"
1", 1¼", 1½"
Number of outlets
EA
1
2
1
Connections, outlet
mm
19/25/32/38
25/32/38
Connections, outlet
¾", 1", 1¼", 1½"
1", 1¼", 1½"
Max. flow rate
l/h
1700
3500
4500
6000
8500
Max. operating pressure
bar
0.50
0.60
Suitable for ponds up to max.
m³
10.0
20.0
25.0
40.0
60.0
Suitable for ponds with fish stock
m³
5.0
10.0
12.5
20.0
30.0
Suitable for ponds with koi*
1
m³
2.5
5.0
6.5
10.0
15.0
Connection to
–
BioSmart 18000/36000, BioTec ScreenMatic
2
40000–60000
–
Other
Visual function check
Item no. (GB-Version)
–
Item no.
57370
56837
56869
56885
57373
*
P.293
Extras
Recommendation
The UVC bulbs should be changed at
regular intervals, ideally in spring before
the season starts, to guarantee the full
capacity of the UVC output!
Top 3 product characteristics
•
Clear pond water via UVC clarification
• Highly effective against suspended algae,
bacteria and germs
• Can be combined with almost all off the
shelf filters
FILTERS, UVC & AERATION
UVC CLARIFIERS
