TECHNICAL DATA
Bitron C
24 W
Bitron C
36 W
Bitron C
55 W
Bitron C
72 W
Bitron C
110 W
Dimensions (L x W x H)
mm
440 x 180 x 198
600 x 180 x 198
730 x 215 x 200
Rated voltage
220–240 V/50/60 Hz
Power consumption
W
24
36
55
72
110
Power cable length
m
5.00
Net weight
kg
3.50
3.97
4.03
6.44
6.50
Guarantee*
P.293
Years
2
UVC power
W
24
36
55
72
110
Temperature display
No
Bypasssteuerung
Manually
UVC operating hours meter
No
Number of inlets
EA
1
Connections, inlet
mm
25/32/38
19/25/32/38/50
Connections, inlet
1", 1¼", 1½"
¾", 1", 1¼", 1½", 2"
Number of outlets
EA
2
Connections, outlet
mm
25/32/38
Connections, outlet
1", 1¼", 1½"
Min. flow rate
l/h
4000
8000
12000
Max. flow rate
l/h
15000
30000
40000
Max. operating pressure
bar
0.50
1.00
Suitable for ponds up to max.
m³
25.0
40.0
60.0
75.0
110.0
Suitable for ponds with fish stock
m³
12.5
20.0
30.0
37.5
55.0
Suitable for ponds with koi*
1
m³
6.5
10.0
15.0
19.0
27.5
Connection to
BioSmart 18000/36000 BioSmart 18000/36000, BioTec ScreenMatic
2
40000–60000
ProfiClear, BioTec 30, BioTec ScreenMatic
2
Other
Visual function check
Item no. (GB-Version)
–
Item no.
56804
56799
56823
56901
56902
Matching filter systems on page 102, 110, 112, 122, 126
Top 3 product characteristics
•
Clever bypass system combines high flow
rates with duration of radiation
• Self cleaning thanks to patented cleaning
rotor
• Highly effective against suspended algae,
bacteria and germs
Automatic cleaning rotor
The automatic cleaning rotor is continu-
ously guided around the quartz glass tube
by the water flow and prevents debris
from settling.
Closure technology
Quick-release fastener for easy opening
of the bulb housing . When opening, a
safety switch deactivates the UVC bulb
to prevent eye injury.
Throttle handle
Easy adjustment of the water flow rate.
Inspection window
The function of the UVC bulb can be che-
cked at any time through the inspection
window.
PRODUCT DETAILS
*
1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m³!
Connection elbow 2″/90° Bitron
for Bitron C 36W–110W and Bitron Eco
Item no. 50540 (page 263)
Recommendation
Do not forget to replace UVC bulbs regularly,
ideally in the spring!
*
P.293
Extras
Accessories
Replacement bulb UVC 24W
Item no. 56237 (page 150)
Replacement bulb UVC 36W
Item no. 55432 (page 150)
Replacement bulb UVC 55W
Item no. 56636 (page 150)
