133
TECHNICAL DATA
ProfiClear Premium Compact
pump fed
ProfiClear Premium Compact
gravity fed
ProfiClear Pump chamber
Compact /Classic
Dimensions (L x W x H)
mm
885 x 685 x 820
830 x 665 x 820
Net weight
kg
70.00
36.50
Guarantee (+ request guarantee)*
P.293
Years
2 + 1
Coarse debris extraction
µm
80
Biological filter surface
m²
38.2
Temperature display
Digital
Connections, sludge discharge
DN 75, DN 110
DN 75
Max. flow rate
l/h
12500
16500
25000
Rated voltage
230 V/50 Hz
Power consumption
W
5
Power consumption cleaning
W
870
Cable length
m
5.00 + 1.00
5.00 + 5.00
Control unit
Microcontroller
Number of nozzles/flush quantity
2 x 3.5 l/min
Flush pump
4 bar
Flush automation
Manual, time interval, sensor
Material
GRP Duroplast/stainless steel
Biological filter surface geschützt
m²
32.2
Number of inlets
EA
2
Connections, inlet
mm
50
Connections, inlet
1 x 2′ + Bitron
DN 110
1 x DN 150 / 2 x DN 110
Connection to
Bitron Eco 120–240 W,
Bitron C 72–110 W, AquaOxy 2000
ProfiClear pump chamber Compact,
Bitron Gravity, AquaOxy 2000
ProfiClear Classic, Bitron Gravity,
AquaMax Eco Gravity
Number of outlets
EA
1
3
Connections, outlet
DN 110
1 x 2′ / 2 x DN 110
Connections, flush trough
DN 110
Min. flow rate
l/h
7500
Suitable for ponds up to max.
m³
80
88
–
Suitable for ponds with fish stock
m³
40
44
–
Suitable for ponds with koi
m³
20
22
–
Type of use
Pump fed system
Gravity fed system Pump fed system, Gravity fed system
Install height above the water level
cm
32.0
10.5
10.5
Other
• Pollutant discharge incl. slide valve, Aeration pre-installed
• Incl. 40l Hel-X 13 Biomedium
• Maximum flexibility in the connec-
tion through DN 110 and 2′ ducts
• Reduction of pressure losses
• Safe and standard-conformant setup
for swim ponds
• Easy maintenance and winter care
• Protection against excessive silt
• Debris that accumulates in the
sediment tank is flushed out via the
bottom drain [2]
Item no. (GB-Version)
42907
42912
–
Item no.
42906
42910
42913
*
P.292
*
P.293
FILTERS, UVC & AERATION
MODULAR FLOW-THROUGH FILTERS
