Module filter
ProfiClear Premium
gravity fed system
Module filter
ProfiClear Premium
pump fed system
AquaOxy aeration pump –
ideal oxygen supply for pond
flora and fauna
Tip!
ProfiClear Premium
2
ProfiClear Premium
Moving Bed Module
3
ProfiClear Premium
Individual Module
Product characteristics
• Extremely large, protected settlement surface
for microorganisms (806 m²/m³)
• Innovative bypass technology for optimal
movement of the Hel-X bio-elements
• Removal of toxins, such as ammonium/
ammonia, nitrite and nitrate
• Hel-X Biomedium: 50 l decompose
approx. 340 g of fish food per day
(can be extended to 100 l/module).
• Aerator bar for oxygen enrichment
and turbulence already installed
• Permanent, optimal oxygen supply;
self-cleaning effect from dead biomass
• Integrated bottom drain with high quality,
finely engineered slide valve
• Space saving pump and UVC chamber
• Maximum flexibility in the connection through
DN 110 and 2" ducts
• To increase the filter capacity, it is possible to
fill the individual baskets in the flow area with
additional filter media up to 8 litres fill volume
• Integrated bottom drain with high quality, finely
engineered slide valve
Dimensions (L x W x H)
mm
830 x 600 x 820
Net weight
kg
44.00
37.00
Guarantee (+ Request Guarantee)*
P.299
Years
2 + 1
Biological filter surface
m²
47.8
–
Biolog. filter surface protected
m²
40.3
–
Individual granulate filter
–
2x 8 litre
Number of sieve elements
EA
–
2
Material
GRP Duroplast
GRP Duroplast/stainless steel
Number of inlets
EA
2
Connections, inlet
mm
180
Number of outlets
EA
2
Connections, outlet
–
50
Connections, outlet
DN 150
2 x 2′ / 2 x DN 110
Connections, sludge discharge
DN 75
Litres per hour, min.
l/h
10000
Max. flow rate
l/h
33000
Connection to
AquaOxy 2000 – 4800
AquaMax Eco Gravity, Bitron Gravity
Installation height above water level
cm
13
Type of use
Pump fed system, gravity-fed system
Other
Pollutant discharge incl. slide valve, aeration pre-installed
Pollutant discharge incl. slide valve
Item no. (GB-Version)
42907
42912
Item no.
50772
50771
