TECHNICAL DATA
WLAN connection technology
At last, you can easily, conveniently, and
quickly read out and regulate the capac-
ity information of your garden devices.
And you can do it with a range of up to
80 m (with unobstructed signal trans-
mission).
DMX-RDM connection
A DMX-RDM interface is provided here
for connecting intelligent, garden system
compatible end devices, such as the Aqua-
Max Eco Expert.
Spike
The ground stake for easy installation
without digging and secure anchoring
in the ground, is included in the scope of
delivery.
Splash guard
To be on the safe side: The InScenio cover
protects the electronic parts from splash-
ing water. In addition, with the optional
InScenio Rock caover the InScenio can be
ideally integrated in the garden world.
PRODUCT DETAILS
InScenio
FM-Master WLAN
Dimensions (L x W x H)
mm
215 x 155 x 295
Rated voltage
220–240 V/50 Hz
Max. total load power
W
3600
Max. total load current
A
16.0
Net weight
kg
1.80
Guarantee*
P.293
Years
2 + 1
Radio range (433 MHz) max.
m
80.00
WLAN range (2.4 GHz) max.
m
80.00
Connection DMX-RDM
Yes
WLAN-Hotspot
Yes
Timer
Yes
Power outlets on/off max. 2000W
EA
3 x 220–240 V
Power outlets, dimmable
EA
1 x max. 40–320 W
Item no. (GB-Version)
40244
Item no.
40243
Top 3 product characteristics
•
Revolutionary device control in the garden
with WLAN, via tablet, or smart phone.
• Connection possibility for DMX-RDM capa-
ble end devices (e.g. AquaMax Eco Expert)
• With radio remote control for up to 10
remote controllable OASE devices
*
P.293
InScenio Rock sand
Cover in rock effect suitable
for all InScenio FM-Master
housings.
Item no. 50417 (page 280)
Accessories
Extras
Recommendation
The OASE InScenio FM-Master WLAN app is
programmed for mobile devices iOS 7.x or
higher, and Android 4.0.3. As soon as valu-
able updates are available there is an auto-
matic notification for the free download. To
ensure the best possible range of the WLAN
connection (2.4 GHz) make sure there is
an unobstructed view between the smart
phone / tablet and the FM-Master. Even
greater distances can be achieved through
off-the-shelf booster antennas or repeaters.
For all OASE products that can be controlled
remotely, such as the FM-Master 1 to Profi-
master, as well as the Water Entertainment
products, Water Trio, Quintet, Quintet
Creative, Jet Lightning and the JumpingJet
Rainbow Star, you can replace the remote
control units with your smart phone / tablet
in combination with the FM-Master WLAN.
Connection cable DMX / 3.0 m /01
Item no. 12369
Connection cable DMX / 5.0 m /01
Item no. 12371
Connection cable DMX / 10.0 m /01
Item no. 12372
Connection cable DMX / 20.0 m /01
Item no. 12373
