MODULFILTER
243
Underwater transformer
UST 150 /01
Connection
cable
2.5 m /01
Connection
cable
5.0 m /01
Connection
cable
7.5 m /01
PowerBox 12 V
AC /01
Dimensions (L x W x H)
mm
154 x 130 x 89
–
75 x 80 x 95
Rated voltage
–
12 V AC
Rated voltage (primary, secondary)
230 V/50 Hz , 12 V/AC
–
Power consumption
W
150
–
Number of cable entries
EA
1
–
1
Number of cable outlets
EA
4
–
2
Power cable length
m
10.00
2.50
5.00
7.50
–
Cable cross section
mm²
1.5
2.5
–
Protection class
IP 68
Net weight
kg
4.46
0.30
0.60
1.20
0.52
Guarantee*
P.293
Years
2
Description
• Robust underwater transformer
for the LunAqua 10 system
• Connection possibility for up to
4 spotlights: 4x 35 W, 3x 50 W,
2x 75 W halogen or 4x 10 W LED
spotlight
• Safe connection and operation of
the light fixtures underwater
• All-round watertight to 4 m
water depth
• Standard regulations do not
allow underwater use of the
UST150 transformer in the swim
pond.
• Robust cable for connecting underwater transformer and
spotlight in the LunAqua 10 system
• Safe connection and operation of the light fixtures
underwater
• All-round watertight to 4 m water depth
• Maximum cable length should not exceed a total of
60m per strand
• Longer connecting cable with larger cable cross-section is
provided in the Commercial Catalogue
• With the OASE
PowerBox up to 12
LunAqua 10 LED
spotlights can be
connected on one
UST 150/01 (up to
8 units in series)
• Safe connection and
operation of the
light fixtures under-
water
• All-round water-
tight to 4 m water
depth
Item no. (GB-Version)
–
Item no.
50401
50402
50403
50404
50492
Connection cable DMX
3.0 m / 01
Connection cable DMX
5.0 m / 01
Connection cable DMX
10.0 m / 01
Connection cable DMX
20.0 m / 01
Power cable length
m
3.00
5.00
10.00
20.00
Cable cross section
mm²
0.34
Protection class
IP 68
Net weight
kg
0.28
0.38
0.63
1.08
Guarantee*
P.293
Years
2
Description
• Special cable suitable for underwater use for bi-directional communication, e.g. between pumps and control devices
• 2-wire, shielded cable with a plug-and-socket connection
Item no.
12369
12371
12372
12373
*
1
Additional instructions concerning the energy efficiency classes are provided on page 285
LUNAQUA 10
CONNECTION
TECHNOLOGY
INSCENIO FM-MASTER
WLAN CONNECTION
TECHNOLOGY
ILLUMINATION & POWER
ACCESSORIES ILLUMINATION & POW
