95
Integrated UVC unit
7/ 9 or 11 watt for clear and healthy water.
Coarse particle strainer
Coarse particles of up to 8 mm in size
are taken out by the strainer.
•
Extras
*
P.293
*
P.292
Top 3 product characteristics
•
Multifunctional compact solution for
prefabricated pools and smaller ponds
up to 5 m³
• Clear water, guaranteed
*P.292
• The technology is virtually invisible
because it must be set up underwater
Recommendation
The UVC bulbs should be changed at
regular intervals, ideally in spring before
the season starts, to guarantee the full
capacity of the UVC output!
Filter media and UVC
Two different filter sponges as well as
bio-surface elements and filter pebbles
ensure mechanical and biological cleaning.
7/ 9 / 11 watt UVC power for clear and
healthy water.
Bio-cores and filter pebbles
The filter pebbles in the net bag and
the bio surface elements offer adequate
settling surface for the micro-organisms.
PRODUCT DETAILS
Replacement bulb UVC 11W
for BioSmart UVC 16000
for BioPress Set 10000
Spare bulb for the integrated
UVC unit in the Filtral UVC 5000.
Item no. 56112 (page 150)
Tradux
Wall and liner transition for
installing either cables or
hoses underwater.
Item no. 57154
(page 262)
Accessories
Replacement bulb UVC 7W
Spare bulb for the integrated
UVC unit in the Filtral UVC 2500.
for BioPress Set 4000.
Item no. 57111 (page 150)
Replacement bulb UVC 9W
for BioPress Set 6000.
Item no. 54984 (page 150)
Replacement filter set Filtral UVC 2500
Consisting of filter
sponges, bio-surface
elements and filter
pebbles.
Item no. 13705
(page 138)
Replacement filter set Filtral UVC 5000
Item no. 35836 (page 138)
TECHNICAL DATA
Filtral
UVC
3000
Filtral
UVC
6000
Filtral
UVC
9000
Dimensions (L x W x H)
mm
247 x 183 x 160
380 x 290 x 160
Rated voltage
230 V/50 Hz
Power consumption
W
20
38
40
Power cable length
m
10.00
Net weight
kg
3.18
4.70
Guarantee*
P.251
Years
2
UVC power
W
7
9
11
Pump capacity max.
l/h
1000
2500
Max. flow rate
l/h
600
1100
Meter water column max.
m
1.30
2.30
Filter intake surface
cm²
232
564
Number of blue filter foams
EA
1
Number of black filter foams
EA
1
Number of bio-surface elements
EA
2
8
Special filter granulate
kg
0.20
0.40
Temperature display
No
Connection, pressure-side
mm
13/19/25
Connection, pressure-side
½′/¾′/1"
Suitable for ponds up to max.
m³
3.0
6.0
9.0
Suitable for ponds with fish stock
m³
1.5
3.0
4.5
Exclusively available in GB !
Item no.
(GB-Version only)
51232
51233
51235
FILTERS, UVC & AERATION
UNDERWATER FILTERS
