93
TECHNICAL DATA
Filtral UVC
2500
Filtral UVC
5000
Dimensions (L x W x H)
mm
247 x 183 x 160
380 x 290 x 160
Rated voltage
230 V/50 Hz
Power consumption
W
20
35
Power cable length
m
10.00
Net weight
kg
3.30
4.96
Guarantee*
P.293
Years
2
UVC power
W
7
11
Pump capacity, max.
l/h
1000
2500
Max. flow rate
l/h
600
1100
Max. head height
m
1.30
2.30
Filter intake surface
cm²
232
564
Number of blue filter foams
EA
1
Number of black filter foams
EA
1
Number of bio-surface elements
EA
2
8
Special filter granulate
kg
0.20
0.40
Temperature display
No
Connection pressure-side
mm
13
Connection pressure-side
½"
Suitable for ponds up to max.
m³
2.5
5.0
Suitable for ponds with fish stock
m³
1.3
2.5
Item no. (GB-Version)
Not available in GB!
Item no.
50446
57379
Top 3 product characteristics
•
Multifunctional compact solution for
prefabricated pools and smaller ponds
up to 5 m³
•
Clear water, guaranteed*
P.292
, and
beautiful fountains
•
The technology is virtually invisible
because it must be set up underwater
Filter media and UVC
Two different filter sponges, as well as bio
surface elements and filter pebbles, ensure
mechanical and biological cleaning. 7/11
watt for clear and healthy water.
Bio-cores and filter pebbles
The filter pebbles in the net bag and the
bio surface elements offer adequate sett-
ling surface for the micro-organisms.
PRODUCT DETAILS
Replacement bulb UVC 11W
for BioSmart UVC 16000 /
BioPress Set 10000
Spare bulb for the integrated
UVC unit in the Filtral UVC 5000.
Item no. 56112 (page 150)
Tradux
Wall and liner transition for
installing either cables or
hoses underwater.
Item no. 57154
(page 262)
Accessories
Replacement bulb UVC 7W
for BioPress Set 4000
Spare bulb for the integrated
UVC unit in the Filtral UVC 2500.
Item no. 57111 (page 150)
Replacement filter set UVC 500–3000
Consisting of filter sponges,
bio-surface elements and
filter pebbles.
Item no. 13705
(page 138)
Replacement filter set Filtral UVC 5000
Item no. 35836 (page 138)
Extras
*
P.293
*
P.292
Vulkan
Lava
Magma
Ø cm H cm Ø cm H cm Ø cm H cm
55
60
20
–
50
60 Filtral UVC 2500
100 100 40
–
100 100 Filtral UVC 5000
Recommendation
The UVC bulbs should be changed at
regular intervals, ideally in spring before
the season starts, to guarantee the full
capacity of the UVC output!
FILTERS, UVC & AERATION
UNDERWATER FILTERS
