H
(mWS)
Q
(l/min)
6
4
2
200
150
100
50
250
300
3
5
1
AquaMax Dry 6000 – 14000
14000
8000
6000
83
TECHNICAL DATA
AquaMax
Dry
6000
AquaMax
Dry
8000
AquaMax
Dry
14000
AquaMax
Dry
16000
Dimensions (L x W x H)
mm
200 x 150 x 150
210 x 150 x 170
Rated voltage
220–240 V/50 Hz
Power consumption
W
75
100
230
260
Power cable length
m
10.00
Net weight
kg
3.10
3.20
5.00
5.10
Guarantee (+ request guarantee)*
P.293
Years
3 + 2
Max. flow rate
l/min
100
125
225
251
Max. flow rate
l/h
6000
7500
13500
15100
Max. head height
m
2.20
3.00
5.00
5.20
Connection pressure-side
mm
38
Connection pressure-side
1½"
Connection suctions-side
mm
38
Connection suctions-side
1½"
Connection for hoses
mm
25/32/38
Connection for hoses
1", 1¼", 1½"
Coarse debris displacement max.
mm
8
Electronic adjustment
Yes
Setup type
Dry installation only
Item no. (GB-Version)
50396
50069
50070
50448
Item no.
50393
50066
50068
GB-Version only!
Extras
Hose clamps
The stainless steel hose clamps are inclu-
ded in the scope of delivery.
Coarse debris displacement
The pump displaces debris particles up to
8 mm in size, such as fish waste or dead
plant remains.
Top 3 product characteristics
•
Quiet pump, especially for dry setup
• Extremely stable thanks to its solid base
• Electronically adjustable with the OASE
InScenio FM-Master 3
Recommendation
The AquaMax Dry should be setup below
the water level in the separate pump
chamber. Consequently, a great advantage
of the dry setup is the extremely safe use,
particularly for swim ponds and bathing
ponds. In addition the pump is easily
accessible for maintenance purposes.
Optionally, the use of slide valves is
recommended. For effective displacement
of polluted water, particularly with the
AquaMax Dry 14000, we recommend
connection of a satellite filter or skimmer,
in combination with a Y-distributor.
Extend the service life of your pump and
ensure lasting high performance with
the special AquaActiv PumpClean cleaner
(page 207).
Accessories
InScenio Dimmer
Item no. 51160 (page 239)
InScenio FM-Master 3
Wireless remote control garden power
outlet for electronic adjustment.
Item no. 36311 (page 238)
Y-distributor 1½"
Water distributor with 1 inlet
and 2 outlets. Both outlets are
individually adjustable. Operate
underwater only!
Item no. 56668 (page 263)
AquaSkim 20
(page 170)
Item no. 51236
AquaSkim 40
(page 170)
Item no. 56907
Skimmers for powerful suctioning
of pond surfaces. Remove particles
before they settle and impair the
water quality.
Satellite filter AquaMax Eco
Enables intake of polluted
water at an additional point
on the pond floor.
Item no. 57177 (page 75)
PRODUCT DETAILS
Matching filters and filter systems starting on page 84
OASE-Pump performance curves – comparison see page 286–288
