Extras
AquaMax Eco Titanium 50000
Q
(l/min)
100 200 300 400 500 600 700 800
H
(mWS)
2
4
3
1
MAX
MIN
79
Connection for DMX-RDM
control devices
The pump can be controlled with inno-
vation and convenience via control de-
vices such as the AquaMax Eco Control
(included in the scope of delivery).
Stainless steel channel type
impeller
The impeller is impressive through its
extremely long service life. Even under
continuous load, signs of wear cannot be
detected.
Robust pump housing
Cast stainless steel enables achievement
of sustainable above-average precision
and energy-efficiency. The entire pump
housing can be adjusted 90° upward.
OASE-Pump performance curves – comparison see page 286–288
PRODUCT DETAILS
*
P.293
Safty grid AquaMax Eco Titanium
Optional pump guard adapter for the
wet installation in a pump chamber –
prevent inadvertend contact with the
rotor by touching the suction intake.
Item no. 43329 (page 75)
Accessories
TECHNICAL DATA
AquaMax Eco Titanium
50000
Dimensions (L x W x H)
mm
350 x 220 x 245
Rated voltage
220–240 V/50/60 Hz
Power consumption
W
70 – 320
Power cable length
m
10.00
Net weight
kg
16.50
Guarantee (+ request guarantee)*
P.293
Years
3 + 2
Max. flow rate
l/min
800
Max. flow rate
l/h
48000
Max. head height
m
4.00
Connection pressure-side
mm
75
Connection pressure-side
3"
Connection suctions-side
mm
75
Connection suctions-side
3"
Coarse debris displacement max.
mm
6
Electronic adjustment
Yes
Setup type
Can be setup underwater & dry
Item no. (GB-Version)
–
Item no.
39918
Recommendation
AquaMax Eco Titanium 50000 is outstan-
dingly suited in this regard, e.g. through a
drum filter, then cleaned water is energy-
efficiently conveyed back into the pond,
even over long distances.
The AquaMax Eco Control with an illumina-
ted two-line display is equipped with a 10
m DMX/RDM cable. Enabling the pump to
be conveniently dimmed, power consump-
tion is displayed; as well as speed and total
runtime.
Extend the service life of your pump and
ensure lasting high performance with the
special AquaActiv PumpClean cleaner.
Top 3 product characteristics
•
Powerful, energy-efficient powerhouse for
large gravity-fed filter systems
• With the innovative AquaMax Eco Control
for regulation and control included in the
scope of delivery
• With the SFC function switched on, an
additional 30% savings in energy costs,
depending on the water temperature is
possible
Connecting cable DMX
Special cable suitable for underwater use for
bi-directional communication between pumps
and control devices.
Connecting cable DMX 3.0 m /01
Item no. 12369 (page 75)
Connecting cable DMX 5.0 m /01
Item no. 12371 (page 75)
Connecting cable DMX 10.0 m /01
Item no. 12372 (page 75)
Connecting cable DMX 20.0 m /01
Item no. 12373 (page 75)
InScenio FM-Master WLAN
This innovative garden power outlet
can be controlled via smart phone or
tablet. In addition to 4 power outlets
with an integrated timer, it also has a
DMX-RDM connection.
Item no. 40243 (page 239)
Item no. 40244 (page 239)
A
NEW
FILTERPUMPEN BACHLAUFPUMPEN
PS &WATERCOURSE PUMPS
FILTER PUMPS &WATERCOURSE PUMPS
