AquaMax Eco Gravity 10000 – 20000
H
(mWS)
Q
(l/min)
3
2
1
50
100
150
200
250
300
15000
10000
20000
81
TECHNICAL DATA
AquaMax
Eco Gravity
10000
AquaMax
Eco Gravity
15000
AquaMax
Eco Gravity
20000
Dimensions (L x W x H)
mm
272 x 142 x 182
Rated voltage
220–240 V/50 Hz
Power consumption
W
65
85
120
Power cable length
m
10.00
Net weight
kg
4.20
4.50
Guarantee (+ request guarantee)*
P.293
Years
3 + 2
Max. flow rate
l/min
167
250
300
Max. flow rate
l/h
10000
15000
18000
Max. head height
m
1.30
1.80
2.20
Connection pressure-side
mm
50
Connection pressure-side
2"
Connection suctions-side
mm
50
Connection suctions-side
2"
Connection for hoses
mm
50/63
Connection for hoses
2", DA 63, DA 75, DA 110
Filter intake surface
cm²
200
Coarse debris displacement max.
mm
6
Electronic adjustment
No
Setup type
Can be setup underwater & dry
Item no. (GB-Version)
–
Item no.
57091
57092
57093
Stainless steel pump guard
Thanks to this high quality, stainless steel
filter basket coarse pollutant particles
up to 6 mm in size are displaced with no
problems.
Removable base
The removable base enables pump
installation in confined spaces.
Adapter Set
The included adapter set enables
connection of hoses (2″/DA 63) and pipes
(DN 75/DN 110).
Top 3 product characteristics
•
Perfectly matched to the requirements of
gravitation filter systems
• High performance with minimal space
requirements
• Patented frost protection to –20 °C
Recommendation
These powerful gravitation filter pumps
are excellently suited for feeding larger
filter systems. Ideal in combination with
the OASE module filters ProfiClear Classic
and ProfiClear Premium (page 124 – 131).
Extend the service life of your pump and
ensure lasting high performance with
the special AquaActiv PumpClean cleaner
(page 207).
OASE-Pump performance curves – comparison see page 286–288
Matching filters and filter systems starting on page 84
PRODUCT DETAILS
Extras
*
P.293
