AquaMax Eco Twin 20000 - 30000
Q
(l/min)
H
(mWS)
450
6
2
1
200
150
100
3
4
5
30000
20000
250 300
400
350
71
Extras
TECHNICAL DATA
AquaMax
Eco Twin
20000
AquaMax
Eco Twin
30000
Dimensions (L x W x H)
mm
380 x 360 x 205
Rated voltage
220–240 V/50/60 Hz
Power consumption
W
20 – 198
20 – 320
Power cable length
m
10.00
Net weight
kg
11.00
Guarantee (+ request guarantee)*
P.293
Years
3 + 2
Max. flow rate
l/min
335
450
Max. flow rate
l/h
20000
27000
Max. head height
m
4.50
5.20
Connection pressure-side
mm
50
Connection pressure-side
2"
Connection suctions-side
mm
50
Connection suctions-side
2"
Connection for hoses
mm
25/32/38/50
Connection for hoses
1", 1¼", 1½", 2"
Filter intake surface
cm²
1300
Coarse debris displacement max.
mm
11
Electronic adjustment
Yes
Setup type
Underwater installation only
Item no. (GB-Version)
–
Item no.
50708
50710
Flexible regulation of the
2 motors
The different water intake functions can
be switched and regulated individually.
The following combinations are possible:
1. Pond floor filtration and satellite filter
2. Pond floor filtration and skimmer
3. Pure pond floor filtration
»Intelligent« flap
The patented »intelligent« flap mechanism
in the interior of the AquaMax Eco Twin
guarantees optimal output even when
only one pump is used.
Controller with LED display
The motors can be separately switched on
or off, or can be adjusted together via wire-
less remote control. Digital display of the
respective capacity level.
Top 3 product characteristics
•
Flexible switching of the flow rate
• On /Off adjustable conveniently via
remote control
• Patented frost protection to –20 °C
Recommendation
Depending on the debris input in the pond,
you can decide from which point the water
should be delivered into the filter. You
can regulate or switch off the pond floor
filtration by remote control, and concent-
rate only on the surface or pond edge. The
pump is so effective.
Extend the service life of your pump and
ensure lasting high performance with
the special AquaActiv PumpClean cleaner
(page 207).
Accessories
OASE-Pump performance curves – comparison see page 286–288
InScenio 230
Spray water resistant garden power
outlet for year round use offers
connection for up to 4 devices.
Item no. 55433 (page 239)
AquaSkim 40
Skimmers for powerful suctioning
of pond surfaces. Remove particles
before they settle and impair the
water quality.
Item no. 56907 (page 170)
Satellite filter AquaMax Eco
Enables intake of polluted
water at an additional point
on the pond floor.
Item no. 57177
(page 75)
PRODUCT DETAILS
Matching filters and filter systems starting on page 84
*
P.293
