AquaMax Eco Expert 21000 - 26000
Q
(l/min)
H
(mWS)
450
6
7
8
9
2
1
200
150
100
3
4
5
26000
21000
250 300
400
350
73
Extras
*
P.293
TECHNICAL DATA
AquaMax
Eco Expert
21000
AquaMax
Eco Expert
26000
Dimensions (L x W x H)
mm
490 x 215 x 210
Rated voltage
220–240 V/50/60 Hz
Power consumption
W
40 – 350
60 – 440
Power cable length
m
10.00
Net weight
kg
12.00
Guarantee (+ request guarantee)*
P.293
Years
3 + 2
Max. flow rate
l/min
350
433
Max. flow rate
l/h
21000
26000
Max. head height
m
8.00
8.50
Connection pressure-side
mm
50
Connection pressure-side
2"
Connection suctions-side
mm
50
Connection suctions-side
2"
Connection for hoses
mm
38/50
Connection for hoses
1½", 2"
Connection DMX-RDM
Yes
Electronic adjustment
Yes
Filter intake surface
cm²
1060
Coarse debris displacement max.
mm
11
Setup type
Can be setup underwater & dry
Item no. (GB-Version)
–
Item no.
39916
39917
Convenient operation
The ergonomic handle, aligned with the
pump‘s centre of gravity facilitates for
transport and installation. The switch
for SFC function is practically positioned
directly on the handle.
Connection for DMX-RDM
control devices
Innovative, convenient and handy, the
AquaMax Eco Expert pumps can be easily
regulated and controlled by devices, such
as the AquaMax Eco Control via a DMX-
RDM connection.
Compact base
Integrated fixing holes in the base facili-
tate fixed installation on the pond floor, as
needed.
Robust filter basket
Thanks to this robust stainless steel
filter basket, coarse debris particles up
to 11 mm in size are displaced with no
problems.
Top 3 product characteristics
•
High-performance powerhouse with low
energy consumption offers significant
energy savings
• Patented frost protection to -20°C
• With switchable SFC function, enabling
an additional 30% savings in energy costs,
depending on the water temperature
Recommendation
The energy-efficient and high-
performance AquaMax Eco Expert is
outstandingly suited for feeding large
filter systems, as well as demanding
watercourses and waterfalls.
Innovative controller and FM-Master
WLAN with DMX-RDM interface for
individual capacity regulation and query,
as accessories.
Extend the service life of your pump and
ensure lasting high performance with
the special AquaActiv PumpClean cleaner
(page 205).
OASE-Pump performance curves – comparison see page 286–288
AquaMax Eco Control
With the clever DMX-RDM
control device, AquaMax Eco
Control, the capacity of the
connected pumps can be
simultaneously queried and
regulated directly on the
controller! Including illumi-
nated display, without
separate power supply!
Item no. 40247 (page 74)
InScenio FM-Master WLAN
This innovative garden power outlet
can be controlled via smart phone or
tablet. In addition to 4 power outlets
with an integrated timer, it also has a
DMX-RDM connection.
Item no. 40243 (page 236)
Item no. 40244 (page 236)
Accessories
PRODUCT DETAILS
Matching filters and filter systems starting on page 84
