Top product characteristics
•
Clever bypass system combines high flow
rates with duration of radiation
• Self cleaning thanks to patented cleaning
rotor
• Highly effective against suspended algae,
bacteria and germs
Automatic cleaning rotor
The automatic cleaning rotor is continu-
ously guided around the quartz glass tube
by the water flow and prevents debris
from settling.
Closure technology
Quick-release fastener for easy opening
of the bulb housing . When opening, a
safety switch deactivates the UVC bulb
to prevent eye injury.
Throttle handle
Easy adjustment of the water flow rate.
Inspection window
The function of the UVC bulb can be che-
cked at any time through the inspection
window.
P
Connection elbow 2″ /90° Bitron
for Bitron C 36W–110W and Bitron Eco
Item no. 50540 (page 280)
Recommendation
Do not forget to replace UVC bulbs regularly,
ideally in the spring!
Extras
Accessories
Replacement bulb UVC 24W
Item no. 56237 (page 155)
Replacement bulb UVC 36W
Item no. 55432 (page 155)
Replacement bulb UVC 55 W
Item no. 56636 (page 155)
*P.310
*1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m
3
!
T
Bitron C 24 W Bitron C 36 W Bitron C 55 W Bitron C 72 W Bitron C 110 W
Dimensions (L x W x H)
mm 440 x 180 x 198
600 x 180 x 198
730 x 215 x 200
Rated voltage
220 - 240 V / 50/60 Hz
Power consumption
W
24
36
55
72
110
Power cable length
m
5.00
Net weight
kg
3.50
3.97
4.03
6.44
6.50
Guarantee
*P.310
Years
2
UVC power
W
24
36
55
72
110
Temperature display
No
Bypass control
manually
UVC operating hours meter
No
Function check
Visual
Number of inlets
EA
1
Connection inlet
mm
25 / 32 / 38
19 / 25 / 32 / 38 / 50
Connection inlet
1”, 1 ¼”, 1 ½”
¾”, 1”, 1 ¼”, 1 ½”, 2”
Number of outlets
EA
2
Connections, outlet
mm
25 / 32 / 38
Connections, outlet
1”, 1 ¼”, 1 ½”
Min. flow rate
l/h
4000
8000
12000
Max. flow rate
l/h
15000
30000
40000
Max. operating pressure
bar
0.5
1
Suitable for ponds up to max.
m³
25.0
40.0
60.0
75.0
110.0
Suitable for ponds with fish stock
m³
12.5
20.0
30.0
37.5
55.0
Suitable for ponds with koi
*1
m³
6.5
10.0
15.0
19.0
27.5
Connection to
BioSmart 18000/36000 BioSmart 18000/36000, BioTec ScreenMatic² 40 - 60000 BioTec 30, BioTec ScreenMatic² 90 - 140000, ProfiClear
Item no. (GB-Version)
−
Item no.
56804
56799
56823
56901
56902
