153
P
Perfect for gravity fed filter systems on koi ponds.
High quality V4A stainless steel
housing
Provides stability and good reflection
rates. Can be used even with increased salt
content (dry setup).
Easy installation
Stainless steel connection elements.
Flexible installation
Possible upstream or downstream of the
filter system. Also ideal for other gravity-
fed applications.
Top product characteristics
•
Powerful, efficient UVC clarifier
• Extremely effective sterilisation thanks to
well thought-out flow optimisation
• Extremely easy and flexible installation
before or after the filter system
Recommendation
Do not forget to replace UVC bulbs regularly,
ideally in the spring!
Can be optimally integrated in the ProfiClear Premium system.
Accessories
Replacement bulb UVC 55 W
Item no. 56636
(page 155)
Discharge pipe black 110/ 480 mm
Item no. 50427
(page 280)
Adapter kit hose Bitron Gravity
Item no. 18127
Connection elbow black 110/ 45°
Item no. 50430
(page 280)
Extras
T
Bitron Gravity 55 W
Dimensions (L x W x H)
mm
700 x 260 x 160
Rated voltage
220 - 240 V / 50/60 Hz
Power consumption
W
55
Power cable length
m
5.00
Net weight
kg
6.98
Guarantee
*P.310
Years
2
UVC power
W
55
UVC operating hours meter
No
Function check
Visual
Number of inlets
EA
1
Connection inlet
DN 110
Number of outlets
EA
1
Connections, outlet
DN 110
Max. flow rate
l/h
30000
Max. operating pressure
bar
0.6
Rec. flow rate (gravity-fed)
l/h
12500
Suitable for ponds up to max.
m³
70.0
Suitable for ponds with fish stock
m³
40.0
Suitable for ponds with koi
*1
m³
25.0
Material
Stainless steel / Plastic / stainless steel
Connection to
AquaMax Eco Gravity, ProfiClear
Type of use
Gravity fed system, Pump fed system
Item no. (GB-Version)
−
Item no.
50946
*P.310
*1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m
3
!
UVC
F
, UVC & A
