Recommendation
Whether on the terrace, in the swim pond
or in the ground - the LunAqua Terra LED
is suitable for various areas of imple-
mentation in the garden or in driveways.
Installation is incredibly easy: Route the
cable, insert the light fixture in the 40
mm bore – a romantic evening atmos-
phere is provided!
Top product characteristics
•
Pleasant warm light out of the ground
for perfect evening atmosphere
• Individual installation possibilities:
In the garden above the water and
underwater
• Easy installation
P
Extras
Stainless Steel Watercourses
Can be combined with the OASE stainless
steel watercourse elements. Simply insert
into the illumination element and the
stainless steel watercourse shells become
radiant highlights (fastening accessories
included in the scope of delivery of the
illumination element).
Maximum drive-over weight 3 t
When properly installed, load bearing
capacity for pedestrian and vehicular
traffic up to 3 t Also suitable for yard and
driveway.
Watertight, in accordance with
IP 68 protection rating
Water ingress is not possible! Thanks to
high-quality workmanship and protection
class IP 68 for continuous safe operation
underwater and above the water (IP 44
connection).
Extension cable
10 m extension cable available as an acces-
sory and suitable for bulb and 6x connec-
tor (max. 2 x per strand)
Accessories
LunAqua Terra LED
Extension cable 10m
Item no. 51057 (page 248)
Stainless steel watercourse
illumination
Item no. 50809 (page 294)
221
*page310
T
LunAqua Terra LED Set 6
LunAqua Terra LED Set 3
LunAqua Terra LED Solo
Dimensions (Ø x H)
mm
45 x 15
Rated voltage
-
12 V / AC
Rated voltage (primary, secondary)
230 V / 50 Hz, 12 V / AC
-
Power consumption light fixture
0.25 W
Power consumption set
W
4
3
-
Protection class
IP 68, IP 44 (power£unit)
IP 68
Power cable length
m
10.00
Net weight
kg
2.18
1.30
0.30
Guarantee
*P.310
Years
2
Illuminant type
LED
Light flux
lm
14
Light colour
Warm-white
Colour temperature
K
3000
Half peak angle
diffuse
Item no. (GB-Version)
Not£available£in GB
Item no.
50729
51043
51056
LED
I & P
