249
L A— 10 š -
›š œ š šžŸ
Underwater transformer
UST 150 /01
Connection
cable 2.5 m /
01
Connection
cable 5.0 m /
01
Connection
cable 7.5 m /
01
PowerBox
12 V AC /01
Dimensions (L x W x H) mm 154 x 130 x 89 - 75 x 80 x 95
Rated voltage - 12 V / AC
Rated voltage (primary, secondary) 230 V / 50 Hz, 12 V / AC -
Power consumption W 150 -
Number of cable entries EA 1 - 1
Number of cable outlets EA 4 - 2
Power cable length m 10.00 2.50 5.00 7.50 -
Cable cross section mm² - 1.5 2.5 -
Protection class IP 68
Net weight kg 4.46 0.30 0.60 1.20 0.52
Guarantee *P.310 Years 2
Product characteristics
• Connection possibility for up
to 4ŒEA spotlights: 4 x 35 W, 3
x 50 W, 2 x 75 W halogen or 4
x 10 W LED spotlight
• Robust underwater trans-
former for the LunAqua 10
system
• Safe connection and oper-
ation of the light fixtures
underwater
• All-round watertight to 4 m
water depth
• Standard regulations do not
allow underwater use of the
UST 150 transformer in the
swim pond.
• Robust cable for connecting underwater trans-
former and spotlight in the LunAqua 10 system
• Safe connection and operation of the light fixtures
underwater
• All-round watertight to 4 m water depth
• Maximum cable length should not exceed a total
of 60 m per strand
• Longer connecting cable with larger cable
cross-section is provided in the Commercial
Catalogue
• With the OASE
PowerBox up to 12
LunAqua 10 LED
spotlights can be
connected on one
UST 150 / 01 (up to
8 units in series)
• All-round water-
tight to 4 m water
depth
• Safe connection
and operation of
the light fixtures
underwater
Item no. (GB-Version) −
Item no. 50401 50402 50403 50404 50492
EGC š ›š
œ š š žŸ
NEW
Connection Cable EGC
2.5 m
Connection Cable EGC
5.0 m
Connection Cable EGC
10.0 m Cable connector EGC
Power cable length m 2.50 5.00 10.00 -
Cable cross section mm² 0.22 -
Protection class IP 68
Net weight kg 0.39 0.69 1.29 0.02
Guarantee *P.310 Years 2
Product characteristics
• Special cable suitable for underwater use for bi-directional communication, e.g. between pumps, filters and control
devices
• 4-wire, shielded cable with a plug-and-socket connection
Item no. (GB-Version)
Item no. 47038 47039 47040 47788
