Extras
Connection possibilities
For up to 4 spotlights, for example with
4 x 35W, 3 x 50W or 2 x 75W halogen
bulbs.
Sets
Available as a practical 35W complete set
and illumination set for the PondJet Eco
floating fountain.
P
Top product characteristics
•
Particularly powerful halogen spotlight
with luminous intensity of up to 1,250
lumen
• Suitable for use underwater and above
the water surface (to 4 m water depth)
• Flexible extension and seamlessly compa-
tible with the LunAqua 10 spotlights
Extras
Recommendation
The cable cross section of the connecting
cable that must be used is 2.5 mm² and
the maximum cable length should not
exceed 60 m per line overall.
Halogen bulb 35 W
Item no. 54035 (page 248)
Halogen bulb 50W
Item no. 54036 (page 248)
Halogen bulb 75 W
Item no. 54037 (page 248)
Accessories
Underwater transformer UST 150 /01
Easy and safe operation above
water and underwater –
standard regulations do not
allow use in swim ponds
Item no. 50401 (page 249)
Connection cable 2.5 m /01
Item no. 50402 (page 249)
Connection cable 5.0 m /01
Item no. 50403 (page 249)
Connection cable 7.5 m /01
Item no. 50404 (page 249)
IP68 connection technology
All connection cables, transformers, and
power supply can be operated constantly
up to 4m under water!
239
*page310
*1
Additional instructions concerning the energy efficiency classes are provided on 302
T
LunAqua 10 LunAqua 35
Set
Illumination
set PondJet
Dimensions (L x W x H)
mm
145 x 160 x 182
Rated voltage
12 V / AC
-
Rated voltage (primary, secondary)
-
230 V / 50 Hz, 12 V / AC
Power consumption light fixture
-
35 W
50 W
Energy efficiency class - light fixture
*1
-
B
Power consumption set
W
-
46
157
Protection class
IP 68 IP68, IP44 (power£unit)
IP 68
Cable length 12 V device
m
- 2.00 (Power unit) + 7.50 20.00(Powerunit)+0.80
Net weight
kg
0.82
2.52
9.34
Guarantee
*P.310
Years
2
Illuminant type
Halogen
Light flux
lm
-
500
750
Light colour
Warm-white
Colour temperature
K
2700
Half peak angle
24 Degrees
Cable cross section
mm²
-
1.5
2.5
Item no. (GB-Version)
−
Item no.
54034
54314
57083
H
I
& P
