ProfiLux Garden
LED RGB
Floating fountain
illumination set
RGB
Dimensions (Ø x H)
mm
80 x 117
Rated voltage
24 V / DC
-
Rated voltage (primary, secondary)
- 230 V / 50 Hz, 24 V / DC
Power consumption light fixture
6 W
Energyefficiencycategorylightficture
*1
A
Power consumption set
W
-
19
Protection class
IP 68
Cable length 24 V device
m
5,00 20,00 (power unit) + 5,00
Net weight
kg
0,60
8,00
Guarantee (+ request guarantee)
*S.310
Jahre
2 + 1
Connection EGC
Yes
Illuminant type
LED
Number of individual LEDs
EA
3
Light colour
RGB
Light flux all on
lm
213
Light flux red
lm
64
Light flux green
lm
114
Light flux blue
lm
35
Half peak angle
25 Degrees
Item no. (GB-Version)
–
Item no.
42638
42641
Accessories
ProfiLux Garden LED Controller
Easy and safe operation above
water and underwater – stan-
dard regulations do not allow
use in swim ponds
Item no. 42639 Page 245
ProfiLux Garden LED cable 7,5 m
7.5 m connecting cable for the
ProfiLux Garden LED RGB
Item no. 42641
Page 245
InScenio FM-Master WLAN EGC
The intelligent switch centre of
the Easy Garden System. Inter-
connects the components and
the home network. Required for
use of the EGC functionalities..
Item no. 42640 Page 245
Connection elbow EGC 2,5 m
Special cable suitable for un-
derwater use for bi-directional
communication between pumps
and control devices
Item no. 47038 Page 245
Connection cable EGC 10,0 m
Item no. 47040 Page 245
Connection cable EGC 5,0 m
Item no. 47039 Page 245
Cable connector EGC
Item no. 47788 Page 245
*P.310
*1
Additonal instructions concerning the energy efficiency classes are provided on page 302
I
& P
LED S
FM-Master WLAN
Thanks to innovative technology, it can be
switched with smart phone or tablet via
WLAN.
Flexible implementation
possibilities
Can be used as fountain illumination,
ground installation through ground stake
or wall installation.
RGB effects
Full colour variety for green oases and
long service life of the LED chips through
excellent thermal management
Professional use
Optimal implementation ever for large
installations
P
Top product characteristics
• Compact & clever: robust RGB spotlights
with patented underwater connection
technology
• No programming effort: Control RGB effects
yourself with total convenience via app
• Can be flexibly extended and can be
installed either above the water surface
or underwater!
Recommendation
The maximum cable length between
controller and light fixture should not
exceed 12.5 m.
