OASE | Catalogue 2017 - page 236

236
L A M E S / L A 2 /
P L / L A 3 S
LunAqua Micro Eco Set LunAqua 2/12 V ProfiLux
LunAqua 2/12 V
Light distribution
in candela (cd)
Luminous intensity
in lux (lx)
Distance
in metres (m)
T  
LunAqua Micro
Eco Set LunAqua 2 / 12 V LunAqua 3 Solo ProfiLux 100 E
Dimensions (Ø x H) mm 12 x 64 74 x 92 80 x 110 160 x 135
Rated voltage 12 V / AC 12 V AC / 50 Hz / 24 V DC 12 V / AC 230 V / 50 Hz
Rated voltage (primary, secondary) 230 V / 50 Hz, 12 V / AC -
Power consumption light fixture 7 W 20 W 100 W
Energy efficiency class - light fixture *1 B D
Power consumption set W 10 - 110
Protection class IP 68, IP 20 (power”unit) IP 68 IP 68, IP 44 (power”unit)
Power cable length m 2.00 3.00 - 7.50
Net weight kg 0.60 0.62 0.44 4.64
Guarantee *P.310 Years 2 3
Illuminant type Halogen
Light flux lm 90 300 -
Light colour Warm-white
Colour temperature K 2700
Half peak angle 300 Degrees 10 - 40 Degrees 24 Degrees
Number of cable entries EA - 2 1
Entry cable size - PG 11 PG 13.5
Transformer Yes No Yes
Item no. (GB-Version) Not”available”in GB −
Product characteristics
• Small compact indoor
fountain light
• Now extremely energy-ef-
ficient and as bright as 10
watt
• Perfect for small bubbling
stones
• A hole diameter of just 13
mm is required in bubbling
stones
• Suitable for use under wa-
ter (protection class IP 68)
• Included in the set: Trans-
former and cable
• Garden light for use
underwater and above
the water
• For connection to the
UST 150 underwater
transformer
• Custom light effects
thanks to the adjustable
beam angle
• With ground stake and
adjustable mounting base
• Garden light for use above
water and underwater in a
new design
• Can be connected in series
or parallel
• 2 cable outlets
• High quality PG couplings
• Incl. mounting element
with adjusting unit and
ground stake
• Incl. 20 W illuminant
• Other 35 W illuminants
can be used
• Bulbs: 100 watt halogen
• High-quality stainless
steel spotlight
• Stainless steel bracket for
simple and safe instal-
lation
• With quick coupling and
105 VA weatherproof
transformer
• Only suitable for underwa-
ter operation!
Item no. 40290 54993 57141 56898
*page310 *2 *page310 *3 *2 *4
*1 Additional instructions concerning the energy efficiency classes are provided on 302
*2 LunAqua Micro Eco Set / LunAqua 2 12 V / LunAqua 3 Solo* ³ ProfiLux E 100 *4 LunAqua Micro Eco Set
