OASE | Catalogue 2017 - page 279

279
Item no.
Connection
for hoses
Connection
for hoses Diameter
Material Description
mm mm
Universal hose connector
1/2” 55362 13 / 19 / 25 ½”, ¾”, 1” 13 PVC
• For connecting different hose
diameters
Universal hose connector 1” 55361 19 / 25 / 32 / 38 ¾”, 1”, 1 ¼”, 1 ½” 25 PVC
Universal hose connector
1 1/2” 55360 19 / 25 / 32 / 38 ¾”, 1”, 1 ¼”, 1 ½” 38 PVC
Universal hose connector
T-piece 1 1/2” 54800 19 / 25 / 32 / 38 ¾”, 1”, 1 ¼”, 1 ½” 38 PVC
H ­€€ ­‚ƒ
Item no.
Connection
for hoses
Connection
for hoses Diameter
Material Description
mm mm
Stainless steel hose clamp 1/2”-3/4” 51206 13 / 19 ½”, ¾” 16-27 Stainless
steel
• Bound in pairs
• In a colourful display
box
Stainless steel hose clamp 3/4”-1” 51207 25 1” 20-32 Stainless
steel
Stainless steel hose clamp 1 1/4”-1 1/2” 51208 32 / 38 1 ¼”, 1 ½” 35-50 Stainless
steel
Stainless steel hose clamp 1 1/2”-2” 55690 38 / 50 1 ½”, 2” 40-60 Stainless
steel
H ­‡ˆ‰Š ‹ƒ ‹ŒŽŒ€‘ ’ ˆ€“ ˆ“ˆŠ‚ ƒ Œ€ Š‡ˆ­
Item no. Execution Diameter Description
SwimFol liner connection DN 50 37252 Single-side sleeve and liner
sheeting 50 • With single side adhesive
union and liner flange
• For sealing with the liner
• High load bearing capacity
SwimFol liner transition DN 50 37254 Dual-side sleeve and liner
sheeting 50
SwimFol KG-liner transition DN 100 37254 Liner sheeting including pipe
section with sleeve 100
Wˆ‡‡ ‚ƒˆ€Œ‚Œ€ & ‡Œ€ ƒ ‚ƒˆ€Œ‚Œ€
H  & ­€€ ­‚ƒ
Recommendation
Cut the stepped hose adapter to a size
that is suitable for the hose diameter.
This prevents throughput losses and fric-
tion losses in the hose system and avoids
pressure losses.
Fast connection of hoses H„ † & ˆ„‰‰†ˆŠ„‹
P„‰Œ C„‰ Š‹ŽˆŠ‘„‰ & L’‰Œ ˆ’“‘‰”
