OASE | Catalogue 2017 - page 280

280
W
Water distributor
Multi WD 1/2”
Water distributor
Multi WD 3/4”
Water distributor
Multi WD 1”
Flow regulator
1 1/2”
Y-distributor
1 1/2”
Number of inlets EA 1
Connection inlet mm 19 / 25 / 32 / 38 25 / 32 / 38
Connection inlet Stepped hose adapter ¾” - 1 ½” Stepped hose adapter
1” - 1 ½”
1 ½”-thread and
stepped hose adapter
¾” - 2”
Number of outlets EA 3 1 2
Connections, outlet mm 13 19 25 25 / 32 / 38
Connections, outlet ½” ¾” 1” Stepped hose adapter1” - 1 ½”
1 ½” with stepped
hose adapter 1” - 1 ½”
Product characteristics
• Ensures optimal interaction between pump, hoses and water outlet.
With double distributor function: Use the included sealing cap to com-
pletely seal one of the three distributor openings if necessary. Each inlet
1” external thread or ½” internal thread.
• For adjustment of
water flow rates
with 2 stepped hose
adapters 1” - ½”
• Water distributor
with 1 inlet and 2
outlets. Both outlets
can be regulated
individually.
• Not suitable for dry
installation.
Item no. (GB-Version) −
Item no. 37101 37158 37159 56630 56668
Item no.
Diameter Length Tilt angle
Description
mm mm °
Bottom drain BD 100 37143 380 380
-
• For secure connection of pond and ProfiClear
modules
• is flanged or bonded to liner
Discharge pipe black DN40/480 mm 50307 40 480
Discharge pipe black DN50/480 mm 50829 50 480
Discharge pipe black DN75/480 mm 55043 70 480
Discharge pipe black DN110/480 mm 50427 105 480
Connection elbow black DN40/45° 50308 40 - 45
Connection elbow black DN50/45° 50833 50 - 45
Connection elbow black DN75/45° 55044 70 - 45
Connection elbow black DN75/87° 55045 70 150 87
Connection elbow black DN110/45° 50430 105 - 45
Connection elbow 2”/90° Bitron 50540 50 - 90
T-piece black DN75 55046 70 - -
