296
• Near-natural elements fit perfectly in the lanscape
• 3 different elements for individual run of the watercourse
• Long service life, robust GRP material
The classics for custom watercourses
T
Watercourse element GRP
straight
Watercourse element GRP
left curve
Watercourse element GRP
right curve
Dimensions (L x W x H) mm 830 x 420 x 110 680 x 600 x 110
Net weight kg 2.60 2.25 2.05
Guarantee *P.310 Years 2
Max. flow rate l/h 3000
Item no. (GB-Version) Not‡available‡in GB
Item no. 36771 36772 36773
W € ‚ƒ€ „ – C
Recommendation
Tips for correct watercourse calculation
- Use the pump performance curve to
identify the required pump capacity. To
deliver the desired water quantity from
the pump to the source of the water-
course minimum hose diameters are
required e.g. up to 20 l/min = 25 mm
(1”) or from 50 l/min 38 mm (1 1/2”) etc.
Pay attention to the pressure loss of the
water supply line; this is also important
for the watercourse. Generally this is
considered with 0.4 mWc. Consequently,
for displacement of greater quantities
of water it is necessary to use a more
powerful filter & watercourse pump.
Larger water quantities increase pipe
friction loss, and a higher capacity pump
is required.
Here is a rule of thumb for determin-
ing the right pump for a watercourse:
Watercourse width in cm x 1.5 l/min. =
capacity in l/min.
