Filter wings
Easy to remove filter wings can be fitted
on the adapters and positioned at the
edge of the pond.
P
Recommendation
The Aquarius Solar Set is part of the OASE
solar system and should ideally be operated
with the SolarModule 35 or the SolarSafe 41.
Top product characteristics
• Flexible setup and operation with solar
energy only
• Perfect solution for locations without
power supply
• Removable filter wings, convenient ad-
justment and cleaning from the edge of
the pond
*page310
T
Aquarius Solar 700 Aquarius Solar 1500
Dimensions (L x W x H)
mm
220 x 130 x 135
Rated voltage
12 V / DC
Power consumption
W
8
17
Power cable length
m
5.00
Net weight
kg
1.40
1.70
Guarantee (+ request guarantee)
*P.310
Years
3 + 2
Max. flow rate
l/min
11
25
Max. flow rate
l/h
700
1500
Max. head height
m
2.00
3.00
Connection pressure-side
mm
13
Connection pressure-side
½”
Connection sunctions-side
mm
19 / 25
Connection sunctions-side
¾” / 1”
Connection for hoses
mm
13 / 19 / 25
Connection for hoses
½”, ¾”, 1”
Filter intake surface
cm²
825
Electronically adjustable
No
Number of nozzles
EA
3
Telescopic nozzle extension
cm
16 - 29
Setup type
Underwater installation only
Item no. (GB-Version)
−
Item no.
56888
56889
Accessories
SolarModule 35
35W power and high efficien-
cy level thanks to innovative
CIS technology.
Item no. 37105 page 246
SolarSafe 41
With a full rechargeable bat-
tery the storage and control
unit of the Aquarius Solar
700/1500 enables solar oper-
ation for up to 8 or 17 hours,
even without sunlight.
Item no. 56896 page 246
LunAqua Solar
With LEDs and a colour disc
set, ensures effective staging
above the water surface and
below the water surface.
Item no. 56894 page 236
Hoses and accessories
Additional information on
suitable OASE hoses and
appropriate accessories
From page 274
Flow regulator
Flow rate on the pump filter and fountain
height can be adjusted from the pond
edge via the regulator on the adapter.
OASE-Pump performance curves – comparison see page 303–306
F
F
&
47
